A thin spherical shell with radius R1 = 4.00 cm is concentric with a larger thin...
A thin spherical shell with radius R1 = 4.00 cm is concentric with a larger thin spherical shell with radius R2 = 7.00 cm . Both shells are made of insulating material. The smaller shell has charge q1=+6.00nC distributed uniformly over its surface, and the larger shell has charge q2=−9.00nC distributed uniformly over its surface. Take the electric potential to be zero at an infinite distance from both shells. What is the magnitude of the potential difference between the surfaces of the two shells?
Homework Answers
Please rate
if any mistake in this answer please comment i will clarify your
doubt . thank you
