Question

A projectile is shot from the edge of a cliff 115 m above ground level with...

A projectile is shot from the edge of a cliff 115 m above ground level with an initial speed of v0 = 56 m/s at an angle of 35.0∘ with the horizontal, as shown in the figure

A-Determine the time taken by the projectile to hit point P at ground level.

B-Determine the distance X of point P from the base of the vertical cliff.

C-At the instant just before the projectile hits point P, find the horizontal and the vertical components of its velocity.

D- At the instant just before the projectile hits point P, find the magnitude of the velocity.

E-At the instant just before the projectile hits point P, find the angle made by the velocity vector with the horizontal.

F- Find the maximum height above the cliff top reached by the projectile.

1 0
Add a comment Improve this question Transcribed image text
✔ Recommended Answer
Answer #1

〇一一4-9t2-t 32-12t t15 tq.126s 56 cos35 x 4. 126 - dz 418.63m 56 cos 35 x v 45.87 mls 3.41 m/s

tan O- 57.32 45-87 丨9-51.330 | below me horizontal 2 2 C56stn 35 2.dy 5063 m

I hope it was helpful.. please rate me positive..

Add a comment
Know the answer?
Add Answer to:
A projectile is shot from the edge of a cliff 115 m above ground level with...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Similar Homework Help Questions
  • A projectile is shot from the edge of a cliff 115 mabove ground level with...

    A projectile is shot from the edge of a cliff 115 m above ground level with an initial speed of 65.0 m/s at an angle of 35.0 with the horizontal, as shown inthe figure. (a) Determine the time taken by theprojectile to hit point P at ground level. (b)Determine the distance X of point P from the base ofthe vertical cliff. At the instant just before theprojectile hits point P, find (c) the horizontal and thevertical components of its velocity, (d)...

  • A projectile is shot from the edge of a cliff 115 m above ground level with...

    A projectile is shot from the edge of a cliff 115 m above ground level with an initial speed of vo = 66 m/s at an angle of 35.0° with the horizontal, as shown in the figure (Figure 1). Figure 1 of 1 Vo 135.0 h=115 m X constants Part A Determine the time taken by the projectile to hit point P at ground level. Express your answer to three significant figures and include the appropriate units. o μΑ ?...

  • how do I solve this problem? Homework 3.1 5- A projectile is shot from the edge...

    how do I solve this problem? Homework 3.1 5- A projectile is shot from the edge of a cliff 115 m above ground level with an initial speed of 65.0 m/s at an angle of 35.0° with the horizontal, as shown in Fig. 3-44. (a) Deter- mine the time taken by the projectile to hit point P at ground level. (b) Determine the distance X of point P from the base of the vertical cliff. At the instant just before...

  • A projectile is shot from the edge of a cliff 80 m above ground level with...

    A projectile is shot from the edge of a cliff 80 m above ground level with an initial speed of 60 m/sec at an angle of 30° with the horizontal. Determine the time taken by the projectile to hit the ground below. 30° A 80 m

  • A projectile is shot from the edge of a cliff 180 m above ground with an...

    A projectile is shot from the edge of a cliff 180 m above ground with an initial speed of 40.0 m/s at an angle of 32° below the horizontal. How much time does it take the projectile to hit the ground?

  • A projectile is shot from the edge of a vertical cliff 60.0 m above the ocean....

    A projectile is shot from the edge of a vertical cliff 60.0 m above the ocean. It has a speed of 100 m/s and is fired at an angle of 35.0° below the horizontal. How far from the foot of the vertical cliff does the projectile hit the water? solution= 79.1 m please show all work

  • A projectile is launched at an initial angle ?0 above the horizontal from the edge of...

    A projectile is launched at an initial angle ?0 above the horizontal from the edge of the top of a cliff that is 15 m high. It hits the ground below, at the level of the base of the cliff, 230 m from the cliff, after a flight time of 4.2 s. a) What was the initial horizontal component of the projectile’s velocity? b) What was the initial vertical component of the projectile’s velocity? c) What were the initial angle...

  • A projectile is launched from the edge of a 50 m high vertical cliff at an...

    A projectile is launched from the edge of a 50 m high vertical cliff at an angle of 30° above horizontal. The projectile hits the ground at a distance of 150 m from the bottom of the cliff. Find the initial and final velocities of the projectile (magnitude and direction) as well as the total displacement performed by the projectile.

  • Sample Problem 5.1 A projectile is launched from a cliff 10.0 meters above level ground with...

    Sample Problem 5.1 A projectile is launched from a cliff 10.0 meters above level ground with a launch velocity of 3.0 m/s and a launch angle θ (0< θ < π /2) above the horizontal. Determine the projectile's a) peak height from the ground, b) velocity right before it hits the ground, c) range (horizontal displacement), and d) angle θ which gives the maximum range if h-0 m. 3.0 m/s Cliff h-10.0 m Groun We were unable to transcribe this...
