The point charges in the figure below are located at the corners of an equilateral triangle 20.0 cm on a side.
The point charges in the figure below are located at the corners of an equilateral triangle 20.0 cm on a side. (Assume that the +x-axis is to the right and the +y-axis is up along the page.)
(a) Find the electric field at the location of qa in the figure, given that qb = +15.00μC and qc = -3.00 μC.
(b) What is the force on qa given that qa = +3.00 nC?
Homework Answers
