1) A 12.3 kg particle is undergoing simple harmonic motion with an amplitude of 1.86 mm....
1) A 12.3 kg particle is undergoing simple harmonic motion with an amplitude of 1.86 mm. The maximum acceleration experienced by the particle is 7.93 km/s2. (a) Find the period of the motion. (b) What is the maximum speed of the particle? (c) Calculate the total mechanical energy of this simple harmonic oscillator.
2) The orbit of the Moon around the Earth as projected along a diameter can be viewed as simple harmonic motion. Calculate the effective force constant k for this motion
3) A block of mass M, at rest on a horizontal, frictionless table, is attached to a rigid support by a spring of force constant k. A bullet of mass m and speed v strikes the block as shown in Fig. 17.33. The bullet remains embedded in the block. Determine the amplitude of the resulting simple harmonic motion in terms of m, M, v, and k.
Homework Answers
Firstly calculate the angular frequency (w)
Then we can find time period, Vmax and Total Mechanical energy
Add Answer to:
1) A 12.3 kg particle is undergoing simple harmonic motion with
an amplitude of 1.86 mm....
A particle attached to a spring with k = 54 N/m is undergoing simple harmonic motion,...
A particle attached to a spring with k = 54 N/m is undergoing simple harmonic motion, and its position is described by the equation x = (5.5 m)cos(7.1t), with t measured in seconds (a) What is the mass of the particle? kg (b) What is the perlod of the motion? (c) What is the maximum speed of the particle? m/s (d) What Is the maximum potentlal energy? (e) What is the total energy?
A block of mass M = 6.20 kg, at rest on a horizontal frictionless table, is...
A block of mass M = 6.20 kg, at rest on a horizontal frictionless table, is attached to a rigid support by a spring of constant k = 6410 N/m. A bullet of mass m = 9.30 g and velocity v→ of magnitude 600 m/s strikes and is embedded in the block (the figure). Assuming the compression of the spring is negligible until the bullet is embedded, determine (a) the speed of the block immediately after the collision and (b)...
A toy of mass 0.155 kg is undergoing simple harmonic motion (SHM) on the end of...
A toy of mass 0.155 kg is undergoing simple harmonic motion (SHM) on the end of a horizontal spring with force constant 305 N/m. When the object is a distance 1.15 times 10^-2 m from its equilibrium position, it is observed to have a speed of 0.305 m/s. What is the total energy of the object at any point of its motion? What is the amplitude of the motion?
A block of mass M = 5.60 kg, at rest on a horizontal frictionless table, is...
A block of mass M = 5.60 kg, at rest on a horizontal frictionless table, is attached to a rigid support by a spring of constant k = 5890 N/m. A bullet of mass m = 9.30 g and velocity v of magnitude 650 m/s strikes and is embedded in the block (the figure). Assuming the compression of the spring is negligible is embedded, determine (a) the speed of the block immediately after the collision and (b) the amplitude of...
A block of mass M = 5.60 kg, at rest on a horizontal frictionless table, is...
A block of mass M = 5.60 kg, at rest on a horizontal frictionless table, is attached to a rigid support by a spring of constant k = 6390 N/m. A bullet of mass m = 8.20 g and velocity of magnitude 710 m/s strikes and is embedded in the block (the figure). Assuming the compression of the spring is negligible until the bullet is embedded, determine (a) the speed of the block immediately after the collision and (b) the...
A block of mass M = 1.94 kg, at rest on a horizontal frictionless table, is...
A block of mass M = 1.94 kg, at rest on a horizontal
frictionless table, is attached to a rigid support by a spring of
constant k = 110 N/m. A bullet of mass m = 4.7 g and velocity of
magnitude 810 m/s strikes and is embedded in the block (Fig. See
below). Assuming the compression of the spring is negligible until
the bullet is embedded, determine (a) the speed of the block
immediately after the collision and (b)...
A particle undergoing simple harmonic motion travels 20 cm during one complete cycle, which lasts 2.4...
A particle undergoing simple harmonic motion travels 20 cm during one complete cycle, which lasts 2.4 seconds: a) What is the amplitude of this motion? b) What is the angular frequency? c) What is the maximum speed of this particle? d) What is the maximum acceleration of the particle? e) Write an equation describing this motion
A simple harmonic oscillator consists of a block attached to a spring, moving back and forth...
A simple harmonic oscillator consists of a block attached to a spring, moving back and forth on a frictionless horizontal surface. Suppose the mass of the box is 5.0 kg. The motion is started by holding the box at .50m from its central position, using a force of 40.0 N. Then the box is let go and allowed to perform simple harmonic motion. What is the amplitude of the motion? What is the spring constant k? What is the maximum...
Energy in simple harmonic motion A 2.90 kg object oscillates with simple harmonic motion on a...
Energy in simple harmonic motion A 2.90 kg object oscillates with simple harmonic motion on a spring of force constant 600 N/m. The maximum speed is 0.800 m/s. A) What is the total energy of the object and the spring? B) What is the maximum amplitude of the oscillation?
A particle of mass 5.0 × 10–3 kg, moving with simple harmonic motion of amplitude 0.15...
A particle of mass 5.0 × 10–3 kg, moving with simple harmonic motion of amplitude 0.15 m, takes 47 s to make 50 oscillations. What is the maximum kinetic energy of the particle?
A particle attached to a spring with k = 54 N/m is undergoing simple harmonic motion, and its position is described by the equation x = (5.5 m)cos(7.1t), with t measured in seconds (a) What is the mass of the particle? kg (b) What is the perlod of the motion? (c) What is the maximum speed of the particle? m/s (d) What Is the maximum potentlal energy? (e) What is the total energy?
A toy of mass 0.155 kg is undergoing simple harmonic motion (SHM) on the end of a horizontal spring with force constant 305 N/m. When the object is a distance 1.15 times 10^-2 m from its equilibrium position, it is observed to have a speed of 0.305 m/s. What is the total energy of the object at any point of its motion? What is the amplitude of the motion?
A block of mass M = 5.60 kg, at rest on a horizontal frictionless table, is attached to a rigid support by a spring of constant k = 5890 N/m. A bullet of mass m = 9.30 g and velocity v of magnitude 650 m/s strikes and is embedded in the block (the figure). Assuming the compression of the spring is negligible is embedded, determine (a) the speed of the block immediately after the collision and (b) the amplitude of...
A block of mass M = 1.94 kg, at rest on a horizontal
frictionless table, is attached to a rigid support by a spring of
constant k = 110 N/m. A bullet of mass m = 4.7 g and velocity of
magnitude 810 m/s strikes and is embedded in the block (Fig. See
below). Assuming the compression of the spring is negligible until
the bullet is embedded, determine (a) the speed of the block
immediately after the collision and (b)...
