Consult Multiple-Concept Example 10 to review an approach to problems such as this. A CD has...

Consult Multiple-Concept Example 10 to review an approach to problems such as this. A CD has a mass of 17 g and a radius of 6.0 cm. When inserted into a player, the CD starts from rest and accelerates to an angular velocity of 16 rad/s in 0.88 s. Assuming the CD is a uniform solid disk, determine the net torque acting on it.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

m=179 r = 6 ani I = MR² = (17x103) (6x10²72 2 I = 306 x 107 kg - m² W = 16 rads wiso rools x = a todo o 6 raid/s2 = 1818 18

0 0
