A converging lens (f = 13.2 cm) is held 7.30 cm in front of a newspaper, the print size of which has a height of 2.04 mm. (a)

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

Answer: M= -7.30 cm ; f = 13.2 cm I= II & I 13.2 V (6730) 7.30 v vs 13.287.30 = -16.33 Com 9.30-13.2part b). m = tv - ha 1 h m= (-16.33) = hz (-7,30) 2004 h2 = 4.56 mm Object distance -16.33 cm indicates that image formed in formed of lens

0 0
