A wheel with total mass 15.7 kg consists of a solid wooden disk with a thin...
A wheel with total mass 15.7 kg consists of a solid wooden disk with a thin metal rim bonded to the disk's edge. It starts from rest and rolls down an incline of height 1.00 m. At the bottom it's going at 3.32 m/s.
a) find the mass of the disk.
b) find the mass of the rim.
Homework Answers
Conservation of mechanical energy
