Homework Answers
By KVL across second loop,
q/C - iR - Vb = 0
q/C - R*dq/dt - Vb = 0
dq/dt = q/RC - Vb/R
dq/[q/RC - Vb/R] = dt
after integrating
RC* ln(q/RC - Vb/R) = t
After applying the limit that q at t=0 will be CVa and at some time t it will be CV,
CV/RC - Vb/R)/(CVa/RC - Vb/R) = e^(-t/RC)
(V - Vb)/(Va - Vb) = e^(-t/RC)
V = Vb + (Va - Vb)e^(-t/RC)
