4. A 130 turn circular coil has a diameter of 5.2 cm. A magnetic field perpendicular...

Question

Question

science physics

Answer 1

Answer #1

Number of turns (N)= 130 Diameter (29) 5.2 cm - nadius (9) = 26cm = 0.026m Area (A)= 192(3.14) (0-026) = 0.00212 m 0B - 0.75

Answer 2
