Use the following data to size (volume in gallons) an activated sludge reactor basin (CFSTR with...
Use the following data to size (volume in gallons) an activated sludge reactor basin (CFSTR with recycle and Monod)
MLSS = 3500 mg/l
MLVSS = 80%
Yield Coeffiecient = 0.6 MLVSS
BOD5 influent to the activated sludge basin = 230 mg/l
BOD5 effluent to the activated sludge basin = 50 mg/l
MCRT is 6 days
Endogenous decay coefficient is 0.06d^-1
flow rate = 7 MGD
Homework Answers
