03 Deduce the structure with a molecular formula of C,HISN 6H 3H 1H, dd 1H, dd 1H, dd 11-17 Hz ? = 2.1 Hz 17 Hz 10Hz =10Hz J=2.1 Hz 2 1H, sept 5 PPM

science chemistry

Answer 1

Answer #1

The quartet at 3.5 ppm (CH2) and triplet at 1.1 ppm (CH3) is due to ethyl group attached to nitrogen

The septet at 2.9 ppm (CH) and doublet at 1.2 ppm (CH3) is due to isopropyl group attached to nitrogen

The peak at 6.1, 5.5 and 4 ppm due to alkene CH2 and CH protons

Therefore The structure of the compound is
