in series betwed ation and (b) the ph Chapter -27 Interference and Wave Nature of Light...

Question

Question

science physics

Answer 1

Answer #1

The distance of the nth bright fringe from the central bright (y) = m*D*(wavelength)/(d);

0.0375 = 2* 3.5* (wavelength)/0.00012; (m = 2 for second order maxima)

wavelength = 6.428* 10^-7 m;

= 642.8 nm.(D option is correct)

Answer 2

Similar Homework Help Questions

1( A) In a Young's double-slit experiment, a set of parallel slits with a separation of...

1( A) In a Young's double-slit experiment, a set of parallel slits with a separation of 0.102 mm is illuminated by light having a wavelength of 576 nm and the interference pattern observed on a screen 3.50 m from the slits. What is the difference in path lengths from the two slits to the location of a third order bright fringe on the screen? 1(B) In a Young's double-slit experiment, a set of parallel slits with a separation of 0.102...
In a Young's Double Slit experiment, the slit separation d is 0.12 mm. When red light...

In a Young's Double Slit experiment, the slit separation d is 0.12 mm. When red light of wavelength 666 nm is used, the resulting interference pattern appears on a distant screen, with the third order bright fringe located at a distance y of 45 mm as measured from the central bright fringe. Calculate the distance (in m) between the slits and the screen. Please quote your answer to two decimal places. The answer is 2.70m, show your work.
A Young's interference experiment is performed with blue-green laser light. The separation between the slits is...

A Young's interference experiment is performed with blue-green laser light. The separation between the slits is 0.500 mm, and the screen is located 3.24 m from the slits. The first bright fringe is located 3.38 mm from the center of the interference pattern. What is the wavelength of the laser light?

In a Young's double-slit experiment the wavelength of light used is 485 nm (in vacuum), and...

In a Young's double-slit experiment the wavelength of light used is 485 nm (in vacuum), and the separation between the slits is 1.5 × 10-6 m. Determine the angle that locates (a) the dark fringe for which m = 0, (b) the bright fringe for which m = 1, (c) the dark fringe for which m = 1, and (d) the bright fringe for which m = 2.
In a Young's double-slit experiment the wavelength of light used is 491 nm (in vacuum), and...

In a Young's double-slit experiment the wavelength of light used is 491 nm (in vacuum), and the separation between the slits is 1.1 × 10-6 m. Determine the angle that locates (a) the dark fringe for which m = 0, (b) the bright fringe for which m = 1, (c) the dark fringe for which m = 1, and (d) the bright fringe for which m = 2.
In a Young's double-slit experiment the wavelength of light used is 465 nm (in vacuum), and...

In a Young's double-slit experiment the wavelength of light used is 465 nm (in vacuum), and the separation between the slits is 1.1 × 10-6 m. Determine the angle that locates (a) the dark fringe for which m = 0, (b) the bright fringe for which m = 1, (c) the dark fringe for which m = 1, and (d) the bright fringe for which m = 2.

In a Young's double-slit experiment the wavelength of light used is 488 nm (in vacuum), and...

In a Young's double-slit experiment the wavelength of light used is 488 nm (in vacuum), and the separation between the slits is 1.2 × 10-6 m. Determine the angle that locates (a) the dark fringe for which m = 0, (b) the bright fringe for which m = 1, (c) the dark fringe for which m = 1, and (d) the bright fringe for which m = 2.
In a Young's double-slit experiment the wavelength of light used is 479 nm (in vacuum), and...

In a Young's double-slit experiment the wavelength of light used is 479 nm (in vacuum), and the separation between the slits is 1.7 × 10-6 m. Determine the angle that locates (a) the dark fringe for which m = 0, (b) the bright fringe for which m = 1, (c) the dark fringe for which m = 1, and (d) the bright fringe for which m = 2.
In a two - slit experiment, the slit separation is 3.00 × m. The interference pattern...

In a two - slit experiment, the slit separation is 3.00 × m. The interference pattern is created on a screen that is 2.00 m away from the slits. If the 7th bright fringe on the screen is 10.0 cm away from the central fringe, what is the wavelength of the light? A) 100 nm B) 204 nm C) 214 nm D) 224 nm E) 234 nm

In a Young's double-slit experiment the wavelength of light used is 481 nm (in vacuum), and...

In a Young's double-slit experiment the wavelength of light used is 481 nm (in vacuum), and the separation between the slits is 1.9 × 10-6 m. Determine the angle that locates (a) the dark fringe for which m = 0, (b) the bright fringe for which m = 1, (c) the dark fringe for which m = 1, and (d) the bright fringe for which m = 2. To 3 significant figures.
