A soap film has an index of refraction n = 1.62. The film is viewed in...
A soap film has an index of refraction n = 1.62. The film is viewed in transmitted light.
(a) At a spot where the film thickness is 925.0 nm, which wavelengths are missing in the transmitted light? (Enter your answers in order, least to greatest, from left to right. If there are more than 3 such visible wavelengths, enter the 3 smallest.)
| nm |
| nm |
| nm |
(b) Which wavelengths are strongest in transmitted light? (Enter
your answers in order, least to greatest, from left to right. If
there are more than 3 such visible wavelengths, enter the 3
smallest.)
| nm |
| nm |
| nm |
Homework Answers
Add Answer to:
A soap film has an index of refraction n = 1.62. The
film is viewed in...
A soap film is viewed in white light. If the film is much thinner than the...
A soap film is viewed in white light. If the film is much thinner than the wavelength of blue light, what is the appearance of the film? a) The soap film appears blue because all others colors are transmitted. b) The soap film appears red because all other colors are transmitted. c) The soap film appears white because it reflects all wavelengths of visible light. d) The soap film appears totally transparent because it reflects no visible light. Please explain...
#14 Thin Soap Films: Maximizing Reflection A soap bubble consists of a film with an index...
#14 Thin Soap Films: Maximizing Reflection A soap bubble consists of a film with an index of refraction of 1.50, with air on either side of the film. What is the minimum thickness of the film such that red light with a wavelength of 700 nm is reflected with the greatest intensity? O A. 117 nm B. 233 nm O C. 350 nm O D. 700 nm #15 Thin Soap Films: Maximizing Reflection A soap bubble consists of a film...
A soap film of index of refraction n=1.33 is 465 nm thick and lies on top...
A soap film of index of refraction n=1.33 is 465 nm thick and lies on top of a glass plate (index of refraction 1.52). Sunlight (which we can assume is made up of all wavelengths between 380 nm to 750 nm) travels through the air and strikes the soap film perpendicularly. a. Draw a diagram indicating the rays which will interfere (reflected from the front surface of the soap and from the soap-glass interface), indicating all phase changes that occur....
Question 17 A soap bubble with index of refraction n 1.3 and a thickness of 325nm....
Question 17 A soap bubble with index of refraction n 1.3 and a thickness of 325nm. When illuminated by white light and viewed directly (perpendicular to the surface), what wavelength in the visible spectrum (375nm to 725nm) will be strongly reflected? Enter answer here 63 nm 63nm Answer 1 of 5 attempts used CHECK ANSWER
A soap film of refractive index n is suspended in air (in a wire frame). The...
A soap film of refractive index n is suspended in air (in a wire frame). The film is illuminated from above by natural sun light. One region of this film is d thick. For this region of the film, at normal incidence, A What are the visible wavelengths that are not reflected by the soap film? B. What are the visible wavelengths reflected at maximum brightness by the soap film? C. Because evaporation, the soap film becomes thinner and thinner....
A soap film bubble (n = 1.33) with air (n = 1.00) on both sides has...
A soap film bubble (n = 1.33) with air (n = 1.00) on both sides has the smallest nonzero film thickness, such that it appears yellow by strongly reflecting light with a wavelength of 570 nm in vacuum. What would be the next smallest thickness for the soap film, such that it still appeared yellow by strongly reflecting 570-nm light? 285 nm 214 nm 665 nm 375 nm 321 nm
A soap film bubble (n = 1.33) with air (n = 1.00) on both sides has...
A soap film bubble (n = 1.33) with air (n = 1.00) on both sides has the smallest nonzero film thickness, such that it appears yellow by strongly reflecting light with a wavelength of 570 nm in vacuum. What would be the next smallest thickness for the soap film, such that it still appeared yellow by strongly reflecting 570-nm light? 285 nm 214 nm 665 nm 375 nm 321 nm
A soap film (n=1.33) is 781 nm thick. White light strikes the film at normal incidence....
A soap film (n=1.33) is 781 nm thick. White light strikes the film at normal incidence. You may want to review (Pages 991 - 997) . Part A What visible wavelengths will be constructively reflected if the film is surrounded by air on both sides? If there is more than one answer, separate them by a comma.
What is the thinnest soap film (excluding the case of zero thickness) that appears black when...
What is the thinnest soap film (excluding the case of zero thickness) that appears black when viewed by reflected light with a wavelength of 480 nm? The index of refraction of the film is 1.33, and there is air on both sides of the film.
The walls of a soap bubble have about the same index of refraction as that of...
The walls of a soap bubble have about the same index of refraction as that of plain water, n=1.33, There is air both inside and outside the bubble. ( a) What wavelengths ( in air) of visible light is most strongly destroyed from a point on a soap bubble where its wall is 500 nm thick? The visible range is 400nm-700nm.
#14 Thin Soap Films: Maximizing Reflection A soap bubble consists of a film with an index of refraction of 1.50, with air on either side of the film. What is the minimum thickness of the film such that red light with a wavelength of 700 nm is reflected with the greatest intensity? O A. 117 nm B. 233 nm O C. 350 nm O D. 700 nm #15 Thin Soap Films: Maximizing Reflection A soap bubble consists of a film...
Question 17 A soap bubble with index of refraction n 1.3 and a thickness of 325nm. When illuminated by white light and viewed directly (perpendicular to the surface), what wavelength in the visible spectrum (375nm to 725nm) will be strongly reflected? Enter answer here 63 nm 63nm Answer 1 of 5 attempts used CHECK ANSWER
A soap film of refractive index n is suspended in air (in a wire frame). The film is illuminated from above by natural sun light. One region of this film is d thick. For this region of the film, at normal incidence, A What are the visible wavelengths that are not reflected by the soap film? B. What are the visible wavelengths reflected at maximum brightness by the soap film? C. Because evaporation, the soap film becomes thinner and thinner....
A soap film bubble (n = 1.33) with air (n = 1.00) on both sides has the smallest nonzero film thickness, such that it appears yellow by strongly reflecting light with a wavelength of 570 nm in vacuum. What would be the next smallest thickness for the soap film, such that it still appeared yellow by strongly reflecting 570-nm light? 285 nm 214 nm 665 nm 375 nm 321 nm
