The momentum density of an electromagnetic wave is defined as . The direction of the momentum density...
The momentum density of an electromagnetic wave is defined
as . The direction of the momentum density denotes the
direction of the propagation of an electromagnetic wave.
At a particular instant, the electric field associated with an
electromagnetic wave propagating in free space is directed along
the positive x-axis and the magnetic field is along the positive
z-axis, as shown in the figure.
What is the direction of propagation for this electromagnetic wave?
The electromagnetic wave propagates:
| A. |
along the positive x-axis; |
|
| B. |
along the negative x-axis; |
|
| C. |
along the positive y-axis; |
|
| D. |
along the negative y-axis; |
|
| E. |
along the positive z-axis; |
|
| F. |
along the negative z-axis. |
