500 J of work is put into a lever arm that is 1 m long by...
500 J of work is put into a lever arm that is 1 m long by applying a constant force perpendicular to the arm, halfway down its length. If the lever had an angular displacement of 10 radians, what force was used to turn it?
50 N
200 N
400 N
100 N
Homework Answers
If you have any doubt, feel free to discuss in the comments.
