A rectangular loop of wire with dimensions 2.43 cm by 8.38 cm and resistance 0.593 Ω
A rectangular loop of wire with dimensions 2.43 cm by 8.38 cm and resistance 0.593 Ω is being pulled to the right out of a region of uniform magnetic field. The magnetic field has magnitude 3.01 T and is directed into the plane of the following figure(Figure 1).
Part A
At the instant when the speed of the loop is 3.09 m/s and it is still partially in the field region, what is the magnitude of the force the magnetic field exert on the loop?
Part B
What is the direction of the force the magnetic field exert on the loop?
Homework Answers
