A circular coil of wire with a radius 4 cm and 150 Turns is placed in...
A circular coil of wire with a radius 4 cm and 150 Turns is placed in a uniform magnetic field of magnitude 0.6 T. The magnetic field is parallel to the area vector; I.e. perpendicular to the plane of the coil. A)What is the magnetic flux through the coil? B)The magnetic field is decreased to 0T in .1 seconds. What is the magnitude of the emf induced in the coil during this time interval?C) If the coil has a resistance per unit length of two ohms per meter, How much current flows in the coil during this time interval?
Homework Answers
Add Answer to:
A circular coil of wire with a radius 4 cm and 150 Turns is
placed in...
A circular coil of wire with radius 4 cm and 20 turns is placed in a...
A circular coil of wire with radius 4 cm and 20 turns is placed in a uniform magnetic field of magnitude 0.3 T. The magnetic field is parallel to the area vector; i.e. perpendicular to the plane of the coil. a) What is the magnetic flux through the coil? b) The magnetic field is decreased to 0 T in 0.1 s. What is the magnitude of the emf induced in the coil during this time interval? c) If the coil...
A circular coil of wire with radius 2 cm and 60 turns is placed in a...
A circular coil of wire with radius 2 cm and 60 turns is placed in a uniform magnetic field of magnitude 0.8 T. The magnetic field is parallel to the area vector; i.e. perpendicular to the plane of the coil. a) What is the magnetic flux through the coil? b) The magnetic field is decreased to 0 T in 0.1 s. What is the magnitude of the emf induced in the coil during this time interval? c) If the coil...
QUESTION 27 A circular coil of wire with radius 3 cm and 50 turns is placed...
QUESTION 27 A circular coil of wire with radius 3 cm and 50 turns is placed in a uniform magnetic field of magnitude 0.4 T. The magnetic field is parallel to the area vector; l.e. perpendicular to the plane of the coll." a) What is the magnetic flux through the coll? b) The magnetic field is decreased to 0 in 0.1s. What is the magnitude of the emf induced in the coll during this time interval? c) If the coil...
A circular coil that has N 280 turns and a radius of r 9.50 cm lies...
A circular coil that has N 280 turns and a radius of r 9.50 cm lies in a magnetic field that has a magnitude of Bo 0.0635 T directed perpendicular to the plane of the coil. what is the magnitude of the magnetic flux Φ B through the coil? T-m2 The magnetic field through the coil is increased steadily to 0.145 T over a time interval of 0.305 s. What is the magnitude |El of the emf induced in the...
A circular coil that has N = 210 turns and a radius of r = 9.00...
A circular coil that has N = 210 turns and a radius of r = 9.00 сm lies in a magnetic field that has a magnitude of Bo = 0.0600 T directed perpendicular to the plane of the coil. What is the magnitude of the magnetic flux Og through the coil? OB = 0.321 The magnetic field through the coil is increased steadily to 0.180 T over a time interval of 0.515 s. What is the magnitude El of the...
A 32-turn circular coil of radius 4.80 cm and resistance 1.00 Ω is placed in a...
A 32-turn circular coil of radius 4.80 cm and resistance 1.00 Ω is placed in a magnetic field directed perpendicular to the plane of the coil. The magnitude of the magnetic field varies in time according to the expression B = 0.010 0t + 0.040 0t2, where B is in teslas and t is in seconds. Calculate the induced emf in the coil at t = 5.20 s. If the flux is changing as a function of time, how...
A 32-turn circular coil of radius 4.80 cm and resistance 1.00 Ω is placed in a...
A 32-turn circular coil of radius 4.80 cm and resistance 1.00 Ω is placed in a magnetic field directed perpendicular to the plane of the coil. The magnitude of the magnetic field varies in time according to the expression B = 0.010 0t + 0.040 0t2, where B is in teslas and t is in seconds. Calculate the induced emf in the coil at t = 5.20 s. If the flux is changing as a function of time, how...
A circular coil that has 120 turns and a radius of 10.0 cm lies in a...
A circular coil that has 120 turns and a radius of 10.0 cm lies in a magnetic field that has a magnitude of 0.0650 T directed perpendicular to the coil. What is the magnetic flux through the coil? (Express your answer to three significant figures.) The magnetic field through the coil is increased steadily to 0.100 T over a time interval of 0.300 s. What is the magnitude of the emf induced in the coil during the time interval? (Express...
A 141 turn circular coil of radius 2.61 cm is immersed in a uniform magnetic field...
A 141 turn circular coil of radius 2.61 cm is immersed in a
uniform magnetic field that is perpendicular to the plane of the
coil. Over an interval of 0.177 s , the magnetic field strength
increases from 53.1 mT to 96.9 mT . Find the magnitude of the
average emf avg induced in the coil during this time interval, in
millivolts.
A 141 turn circular coil of radius 2.61 cm is immersed in a uniform magnetic field that is...
A 23-turn circular coil of radius 3.40 cm and resistance 1.00 Ω is placed in a...
A 23-turn circular coil of radius 3.40 cm and resistance 1.00 Ω is placed in a magnetic field directed perpendicular to the plane of the coil. The magnitude of the magnetic field varies in time according to the expression B = 0.010 0t + 0.040 0t2, where B is in teslas and t is in seconds. Calculate the induced emf in the coil at t = 5.40 s. mV
A circular coil of wire with radius 2 cm and 60 turns is placed in a uniform magnetic field of magnitude 0.8 T. The magnetic field is parallel to the area vector; i.e. perpendicular to the plane of the coil. a) What is the magnetic flux through the coil? b) The magnetic field is decreased to 0 T in 0.1 s. What is the magnitude of the emf induced in the coil during this time interval? c) If the coil...
QUESTION 27 A circular coil of wire with radius 3 cm and 50 turns is placed in a uniform magnetic field of magnitude 0.4 T. The magnetic field is parallel to the area vector; l.e. perpendicular to the plane of the coll." a) What is the magnetic flux through the coll? b) The magnetic field is decreased to 0 in 0.1s. What is the magnitude of the emf induced in the coll during this time interval? c) If the coil...
A circular coil that has N 280 turns and a radius of r 9.50 cm lies in a magnetic field that has a magnitude of Bo 0.0635 T directed perpendicular to the plane of the coil. what is the magnitude of the magnetic flux Φ B through the coil? T-m2 The magnetic field through the coil is increased steadily to 0.145 T over a time interval of 0.305 s. What is the magnitude |El of the emf induced in the...
A circular coil that has N = 210 turns and a radius of r = 9.00 сm lies in a magnetic field that has a magnitude of Bo = 0.0600 T directed perpendicular to the plane of the coil. What is the magnitude of the magnetic flux Og through the coil? OB = 0.321 The magnetic field through the coil is increased steadily to 0.180 T over a time interval of 0.515 s. What is the magnitude El of the...
A 141 turn circular coil of radius 2.61 cm is immersed in a
uniform magnetic field that is perpendicular to the plane of the
coil. Over an interval of 0.177 s , the magnetic field strength
increases from 53.1 mT to 96.9 mT . Find the magnitude of the
average emf avg induced in the coil during this time interval, in
millivolts.
A 141 turn circular coil of radius 2.61 cm is immersed in a uniform magnetic field that is...
