The gearbox shown here is used to change the speed of rotation. Two shafts support gears...
Problem 1 (25 Points) Two solid steel (6-80 GPa) shafts are connected by the gears shown. Shaft (1) has a diameter of 45 mm, and shaft (2) has an outside diameter of 55 mm and wall thickness 4 mm. Assume that the bearings shown allow free rotation of the shafts. If a 400 N-m torque is applied at gear D, determine (a) the maximum shear stress magnitudes in each shaft. (b) the angles of twist ф, and ф (c) the...
2. (30pts) Consider the gears in a speed- 40 s 450 rev/min change gearbox used in machine tool 25T Input applications. By sliding the ecluster gears on shafts B and C. nine speed changes can be obtained. Find the angular velocity of the following shift 7 25T а) 2-5-5-8 b) 3-6-7-10 c) 4-7-6-9 35T 401 BOT
The solid steel shafts (G=77GPa) are surrounded by the gears
shown. A torque T=340 N.m is applied at point A, determine:
1. The shear stress in shaft EC;
2. The angle through which end A rotates.
The solid steel shafts (G-77GPa) are sITounded by the gears shown. A torque T 340 N.m is applied at point A, determine: 1. The shear stress in shaft EC 2. The angle through which end A rotates. 30 mm 200 mm 400 mm 60...
Required information Two solid steel shafts are connected by the gears shown. A torque of magnitude T = 960 N.m is applied to shaft AB. The allowable shearing stress is 50 MPa. 240 mm 80 mm Considering only stresses due to twisting, determine the required diameter of shaft CD. The diameter of shaft CD is mm.
shown in Figure 2. Two circular disks A and B are welded to the ends of both bars. The disks lie in planes disks A and B subjecting the bars to torsion. If the allowable maximum shear stress is 35 MPa and the allowable rate of twist is 3°/m for both bars, determine the smallest outer diameter (D, and Di) of both bars. The shear modulus of elasticity is 39 GPa to the axes of the bars. Forces 15 kN...
The motor shown in the figure supplies 14.0 kW at 1880 rpm at
A. Shafts (1) and (2) are each solid 26 mm diameter
shafts. Shaft (1) is made of an aluminum alloy [?G=26??GPa], and
shaft (2) is made of bronze [?G=45??GPa]. The shaft lengths are
L1=3.1m and L2=2.7m, respectively. Gear B has 55 teeth,
and gear C has 99 teeth. The bearings shown permit free
rotation of the shafts. Determine:
(a) the maximum shear stress produced in shafts
(1)...
I will rate you
2. A compound shaft consists of two solid shafts that re connected at flange B and se attached to rigid walls at A and C. Shaft (1) is a 3.00-in-diameter solid aluminum [G 4000 ksi] shaft that is 60 in. long. Shaft (2) is a 2.00-in-diameter solid bronze [G- 6500 ksi] shaft that is 40 in. long. If a concentrated torque of 32 kip-in is applied at flange B, determine: (a) The maximum shear stress magnitudes...
Design a gearbox for lifting a weight of W = 1500 Kg with a
pulley as shown in figure, the diameter of the pulley is the
designer decision. The speed of lifting weight should be 40
meter/min. The design has to be compact with the least
manufacturing cost.
Shafts
You must also be able to draw the shear force and bending
moment diagrams, as well as drawing the free-body diagrams and
calculating the reactions at the supports. Since the shafts...
The two 3-ft-long shafts are made of 2014-16 aluminum. Each has a diameter of 1.5 in. and they are connected using the gears fixed to their ends. Their other ends are attached to fixed supports at A and B. They are also supported by bearings at C and D, which allow free rotation of the shafts along their axes. (Figure 1) A torque of T=500 lb-ft is applied to the top gear as shown. Part A Determine the maximum shear...
P2. Two solid steel shafts, each of 30-mm diameter, are connected by the gears shown. Knowing that G- 77.2 GPa, determine the angle through which end A rotates when a torque of magnitude T= 200 N.m is applied at A. 0.2 m 30 mm 0.4 m 0.2m 60 mm 0.1m 90 mm 30 mm 0.5 m
