use method of joints to determine force in each member and state whether in tension or...

Question

Question

use method of joints to determine force in each member and state whether in tension or compression

Free Body Diagram 69cm Hart F FAT125CH/ 17.25cm x 17.250 17.250 A B C D - 7 V 253.25N

engineering Civil-Engineering

Answer 1

Answer #1

sont loem From symmetry Ay=ty Ety =0 => Ay +Ey = 25.3.2 110om D =126,625N by = 126.625 253.25 12.3s 17-25 17.25 17.35 TAB So,

Answer 2

Similar Homework Help Questions

Using the method of joints, determine the force in each member of the truss shown. State...

Using the method of joints, determine the force in each member of the truss shown. State whether each member is in tension or compression. 7 kN 24 kN 7 kN B с А 0.8 m DO E F 8 kN -1.5 m- -1.5 m
Using the method of joints, determine the force in each member of the truss shown. State...

Using the method of joints, determine the force in each member of the truss shown. State whether each member is in tension or compression. -3 m А 1.25 m B 4m 84 kN
Using the method of joints, determine the force in each member of the truss shown

Using the method of joints, determine the force in each member of the truss shown. State whether each member is in tension or compression

2. Using method of joints, determine force in each member of the truss and state whether...

2. Using method of joints, determine force in each member of the truss and state whether it is in tension or compression. (2 20-40) a) 22 kips 13 12 22 kips 24 kips 24 kips b) 8 kips 12' 24 kips 12' 36 kips 16 16
2. Using the method of joints, determine the force in each member of the truss shown....

2. Using the method of joints, determine the force in each member of the truss shown. State whether each member is in tension or compression.
1. Using the method of joints, determine the force in each member of the truss shown...

1. Using the method of joints, determine the force in each member of the truss shown Figure 1. State whether each member is in tension or compression (25 marks). 5 600 Ib 5 7 5

Using method of joints, determine the force in each member of the truss and state if...

Using method of joints, determine the force in each member of the truss and state if the members are in tension or compression. Assume the truss have no weight.
Using the method of joints, determine the force in each member of the truss shown.

Using the method of joints, determine the force in each member of the truss shown. State whether each member is in tension or compression. Locate the centroid of the plane area shown below:
Determine the force in each member of the Fink roof truss shown using Method of Joints....

Determine the force in each member of the Fink roof truss shown using Method of Joints. State whether each member is in tension or compression. Forces A= 5 kN, B= 10kN, D= 10 kN , F = 10 kN ,and G = 5kN 2.25 m 2.25 m KN A 3 m3 m3 m

Determine the force in each member of the truss and state whether it is in tension...

Determine the force in each member of the truss and state whether it is in tension or compression. F3-4. Determine the force in each member of the truss and state whether it is in tension or compression. 2k 8 ft 6 ft F3-4 ㅡㅡㅡㅡㅡㅡ
