In a circuit with a 40 kΩ resistor and an initially charged capacitor with C= 100...
In a circuit with a 40 kΩ resistor and an initially charged capacitor with C= 100 µF, how much time does it take for the capacitance to fall to 20% of it's initial value?
a) 3.2 s
b) 6.4 s
c) 12.8 s
d) none of the above
Explain your answer and show workings
Homework Answers
Add Answer to:
In a circuit with a 40 kΩ resistor and an initially charged
capacitor with C= 100...
For a charging capacitor in an RC circuit with R = 100 kΩ and C =...
For a charging capacitor in an RC circuit with R = 100 kΩ and C = 1 µF, and in series with a battery with emf E = 12 V, (a) how long does it take for the capacitor to charge up to 80% of its final charge? (b) What is the current in the circuit at that point in time?
A 20 μF capacitor initially charged to 30 μC is discharged through a 1.5 kΩ resistor....
A 20 μF capacitor initially charged to 30 μC is discharged through a 1.5 kΩ resistor. How long does it take to reduce the capacitor's charge to 10 μC?
A 30.0 μF capacitor initially charged to 30.0 μC is discharged through a 2.20 kΩ resistor....
A 30.0 μF capacitor initially charged to 30.0 μC is discharged through a 2.20 kΩ resistor. How long does it take to reduce the capacitor's charge to 15.0 μC ?
A 30.0 μF capacitor initially charged to 20.0 μC is discharged through a 2.60 kΩ resistor....
A 30.0 μF capacitor initially charged to 20.0 μC is discharged through a 2.60 kΩ resistor. How long does it take to reduce the capacitor's charge to 10.0 μC ?
A 30.0 μF capacitor initially charged to 30.0 μC is discharged through a 2.50 kΩ resistor.
A 30.0 μF capacitor initially charged to 30.0 μC is discharged through a 2.50 kΩ resistor. How long does it take to reduce the capacitor's charge to 15.0 μC?
A 15 μF capacitor initially charged to 30 μC is discharged through a 1.3 kΩ resistor....
A 15 μF capacitor initially charged to 30 μC is discharged through a 1.3 kΩ resistor. How long does it take to reduce the capacitor's charge to 10 μC?
A 30.0 μF capacitor initially charged to 30.0 μC is discharged through a 2.40 kΩ resistor.
Part AA 30.0 μF capacitor initially charged to 30.0 μC is discharged through a 2.40 kΩ resistor. How long does it take to reduce the capacitor's charge to 15.0 μC?
A charged capacitor is connected to a resistor and a switch in a given electrical circuit....
A charged capacitor is connected to a resistor and a switch in a given electrical circuit. The circuit has a time constant of 2.0 s. Find the capacitance if it resistance is R = 280 kΩ?
A 20 μF capacitor initially charged to 30 μC is discharged through a 1.0 kΩ resistor....
A 20 μF capacitor initially charged to 30 μC is discharged through a 1.0 kΩ resistor. How long does it take to reduce the capacitor's charge to 9.0 μC? Express your answer using two significant figures in ms
a) A 19.1 kΩ resistor and a capacitor are connected in series and then a 12.0...
a) A 19.1 kΩ resistor and a capacitor are connected in series and then a 12.0 V potential difference is suddenly applied across them. The potential difference across the capacitor rises to 3.51 V in 1.49 µs. (i) Calculate the time constant of the circuit. (ii) Find the capacitance of the capacitor. b) The potential difference between the plates of a leaky (meaning that charge leaks from one plate to the other) 2.2 µF capacitor drops to one-fourth its initial...
