A 5.80-kg box sits at rest at the bottom of a ramp that is 8.20 m...
A 5.80-kg box sits at rest at the bottom of a ramp that is 8.20 m long and that is inclined at 40.0 ∘ above the horizontal. The coefficient of kinetic friction is μk = 0.40, and the coefficient of static friction is μs = 0.43.
What constant force F , applied parallel to the surface of the ramp, is required to push the box to the top of the ramp in a time of 4.00 s ?
Express your answer with the appropriate units
Homework Answers
Add Answer to:
A 5.80-kg box sits at rest at the bottom of a ramp that is 8.20
m...
A 61 kg box sits at the bottom of a ramp inclined at 35*; the rough...
A 61 kg box sits at the bottom of a ramp inclined at 35*; the rough surface of the incline has a coefficient of kinetic friction at 0.24. When given a push of 87 N, the box begins moving with an initial speed of 5.6 m/s. Eventually, the box comes to rest. How high above the bottom of the ramp will the box be when it stops moving?
Problem#5: A box with mass 12,0 kg moves on a ramp that is inclined at an...
Problem#5: A box with mass 12,0 kg moves on a ramp that is inclined at an angle of 60.0 above the horizontal. The coefficient of kinetic friction between the box and the ramp surface is M = 0.380. a) Draw a free body diagram b) Express all required equations c) Calculate the magnitude of the acceleration of the box if you push on the box with a constant 150.0 N that is parallel to the ramp surface and directed down...
A box of mass m = 2.00 kg is positioned on a ramp at an angle...
A box of mass m = 2.00 kg is positioned on a ramp at an angle θ. The length of the ramp (minus the width of the base of the box) is d = 3.00 m. The surface of the ramp has a coefficient of static friction μs = 0.500 and a coefficient of kinetic friction μk = 0.350. The angle θ is slowly increased until the box starts to slide down the ramp. Calculate the angle θmax at which...
8. A box of mass m =22 kg is at rest on a ramp inclined at...
8. A box of mass m =22 kg is at rest on a ramp inclined at 45° to the horizontal. The coefficients of friction between the box and the ramp are Us = 0.78 and Uk = 0.65. (a) Determine the magnitude of the largest force that can be applied upward, parallel to the ramp, if the box is to remain at rest. (b) Determine the magnitude of the smallest force that can be applied onto the top of the...
A 5.00 kg box sits on a ramp that is inclined at 37.3 ∘ above the...
A 5.00 kg box sits on a ramp that is inclined at 37.3 ∘ above the horizontal. The coefficient of kinetic friction between the box and the ramp is 0.27. What horizontal force is required to move the box up the incline with a constant acceleration of 4.30 m/s2 ?
A 22.8 kg box is placed at the bottom of a 39.7° ramp whose surface is...
A 22.8 kg box is placed at the bottom of a 39.7° ramp whose surface is rough enough that the coefficient of kinetic friction is 0.222. You push on the box parallel to the ramp's surface, so that the box accelerates up the ramp at 0.911 m/s2. What must be the force (in N) supplied by you?
A box (mass 25.8 kg) sits on a rough incline that makes an angle α =...
A box (mass 25.8 kg) sits on a rough incline that makes an angle α = 28.1o with the horizontal. A massless string is tied to the box, runs parallel to the incline, passes over a massless, frictionless pulley, and is tied to mass M hanging on the other end. Assume μs = 0.455 is the coefficient of static friction between the box and the surface of the plane. Find the maximum value of M, in kg, for which this...
A 30-kg box is at rest on a horizontal floor with friction coefficients μs = 0.65...
A 30-kg box is at rest on a horizontal floor with friction coefficients μs = 0.65 (static) and μk = 0.55 (kinetic). You push on the box HORIZONTALLY (parallel to the floor) with varying applied force. For each applied force below, find the magnitude of the friction force exerted by the floor on the box (in Newtons), and state whether the friction is static or kinetic. (a) Applied force 100 N. (b) Applied force 150 N. (c) Applied force 190...
oblem 2: A 5-kg box slides down a ramp. The ramp is l m in length...
oblem 2: A 5-kg box slides down a ramp. The ramp is l m in length and inclined at an angle of 30° as shown. The box starts from rest at the top. The surface friction coefficient is 0.25 1. Use energy methods to determine the speed of the box at the bottom of the ramp 2. How far does the box slide before stopping on the horizontal floor if it continues to experience the same friction coefficient. 1.00 m...
A 7.75 kg block is sent up a ramp inclined at an angle θ=36.5° from the...
A 7.75 kg block is sent up a ramp inclined at an angle θ=36.5° from the horizontal. It is given an initial velocity of v0=15.0 m/s up the ramp. Between the block and the ramp, the coefficient of kinetic friction is μk=0.444 and the coefficient of static friction is μs=0.790. How far up the ramp in the direction along the ramp does the block go before it comes to a stop?
Problem#5: A box with mass 12,0 kg moves on a ramp that is inclined at an angle of 60.0 above the horizontal. The coefficient of kinetic friction between the box and the ramp surface is M = 0.380. a) Draw a free body diagram b) Express all required equations c) Calculate the magnitude of the acceleration of the box if you push on the box with a constant 150.0 N that is parallel to the ramp surface and directed down...
8. A box of mass m =22 kg is at rest on a ramp inclined at 45° to the horizontal. The coefficients of friction between the box and the ramp are Us = 0.78 and Uk = 0.65. (a) Determine the magnitude of the largest force that can be applied upward, parallel to the ramp, if the box is to remain at rest. (b) Determine the magnitude of the smallest force that can be applied onto the top of the...
oblem 2: A 5-kg box slides down a ramp. The ramp is l m in length and inclined at an angle of 30° as shown. The box starts from rest at the top. The surface friction coefficient is 0.25 1. Use energy methods to determine the speed of the box at the bottom of the ramp 2. How far does the box slide before stopping on the horizontal floor if it continues to experience the same friction coefficient. 1.00 m...
