Water flows at a rate of 21 L/min through a horizontal 8.0-cm-diameter pipe under a pressure...
Water flows at a rate of 21 L/min through a horizontal 8.0-cm-diameter pipe under a pressure of 3.8 Pa . At one point, calcium deposits reduce the cross-sectional area of the pipe to 39 cm2 .
What is the pressure at this point? (Consider the water to be an ideal fluid.)
Express your answer using two significant figures.
p= Pa
Homework Answers
Add Answer to:
Water flows at a rate of 21 L/min through a horizontal
8.0-cm-diameter pipe under a pressure...
Water flows at a rate of 22 L/min through a horizontal 7.0-cm-diameter pipe under a pressure...
Water flows at a rate of 22 L/min through a horizontal 7.0-cm-diameter pipe under a pressure of 17.0 Pa . At one point, calcium deposits reduce the cross-sectional area of the pipe to 21 cm2 . What is the pressure at this point? (Consider the water to be an ideal fluid.) Express your answer using two significant figures.
Water flows at a rate of 660.0 liters/min through a horizontal 6.00-cm diameter pipe under a...
Water flows at a rate of 660.0 liters/min through a horizontal 6.00-cm diameter pipe under a pressure of 5.50 × 105 Pa. At one point, calcium deposits reduce the cross-sectional area of the pipe to 6.50 cm². What is the pressure at this point? Pa
10. Water flows at a rate of 610.0 liters/min through a horizontal 5.10-cm diameter pipe under...
10. Water flows at a rate of 610.0 liters/min through a horizontal 5.10-cm diameter pipe under a pressure of 6.20x10^5 Pa. At one point, calcium deposits reduce the cross-sectional area of the pipe to 5.50 cm². What is the pressure at this point?
Problem 15 Water flows through a horizontal pipe of cross-sectional area 10 cm3 at a pressure...
Problem 15 Water flows through a horizontal pipe of cross-sectional area 10 cm3 at a pressure of 0.25 atm. The flow rate is 1.0 L/s. At a valve, the effective cross-sectional the valve? I area of the pipe is reduced to 5.0 cm. What is the pressure at A) 0.235 atm B) 0.200 atm C) 0.157 atm D) 0.112 atm E) 7.7x10 Pa
A 7.5-cm-diameter horizontal pipe gradually narrows to 4.0 cm . When water flows through this pipe...
A 7.5-cm-diameter horizontal pipe gradually narrows to 4.0 cm . When water flows through this pipe at a certain rate, the gauge pressure in these two sections is 30.0 kPa and 22.0 kPa , respectively. What is the volume rate of flow? Express your answer using two significant figures.
Water flows through a horizontal pipe at a rate of 80 ft3/min. A pressure gauge placed...
Water flows through a horizontal pipe at a rate of 80 ft3/min. A pressure gauge placed on a 3.2 inch diameter section of the pipe reads 15 psi. What is the gauge pressure in a section of pipe where the diameter is 5 inches? Pressure = ______ psi
Water flows in the horizontal pipe shown in the figure. At point A the area is...
Water flows in the horizontal pipe shown in the figure.
At point A the area is 26.0 cm2 and the
speed of the water is 2.20 m/s. At B the area is 15.0
cm2. The fluid in the manometer is mercury, which has a
density of 13,600 kg/m3. We can treat water as an ideal
fluid having a density of 1000 kg/m3. What is the
manometer reading h?
Question 10 (1 point) Water flows in the horizontal pipe shown in...
In a section of horizontal pipe with a diameter of 4.0 cm, the pressure is 47...
In a section of horizontal pipe with a diameter of 4.0 cm, the pressure is 47 kPa and water is flowing with a speed of 2.0 m/s. The pipe narrows to 2.0 cm. What is the pressure in the narrower region? Treat the water as an ideal incompressible fluid. The density of water is 1000 kg/m3 . (1 kPa = 1000 Pa)
A 6 0-cm-diameter horizontal pipe gradually narrows to 4 0 cm When water flows through this...
A 6 0-cm-diameter horizontal pipe gradually narrows to 4 0 cm When water flows through this pipe at a certain rate, the gauge pressure in these two sections is 33.0 kPa and 24.0 kPa, respectively. What is the volume rate of flow? Express your answer using two significant figures. m3/s
Water is flowing in a straight horizontal pipe of variable cross section. Where the cross-sectional area...
Water is flowing in a straight horizontal pipe of variable cross section. Where the cross-sectional area of the pipe is 3.70·10-2 m2, the pressure is 8.10·105 Pa and the velocity is 0.660 m/s. In a constricted region where the area is 16.90·10-4 m2, what is the velocity? Tries 0/15 What is the pressure (in Pa)? (Assume an ideal fluid)
Problem 15 Water flows through a horizontal pipe of cross-sectional area 10 cm3 at a pressure of 0.25 atm. The flow rate is 1.0 L/s. At a valve, the effective cross-sectional the valve? I area of the pipe is reduced to 5.0 cm. What is the pressure at A) 0.235 atm B) 0.200 atm C) 0.157 atm D) 0.112 atm E) 7.7x10 Pa
Water flows in the horizontal pipe shown in the figure.
At point A the area is 26.0 cm2 and the
speed of the water is 2.20 m/s. At B the area is 15.0
cm2. The fluid in the manometer is mercury, which has a
density of 13,600 kg/m3. We can treat water as an ideal
fluid having a density of 1000 kg/m3. What is the
manometer reading h?
Question 10 (1 point) Water flows in the horizontal pipe shown in...
A 6 0-cm-diameter horizontal pipe gradually narrows to 4 0 cm When water flows through this pipe at a certain rate, the gauge pressure in these two sections is 33.0 kPa and 24.0 kPa, respectively. What is the volume rate of flow? Express your answer using two significant figures. m3/s
