A 2.60-kg block is attached to a horizontal spring that has a spring constant of 259...
A 0.2-kg block on a horizontal, frictionless surface is attached to a horizontal spring. The spring constant is k = 600 N/m. The block is pulled to the right until it is a distance of 0.08 m from the unstrained position and released from rest. What is the kinetic energy of the block when it is 0.06 m from the unstrained position?
1) A block of mass m = 0.52 kg is attached to a spring with
force constant 119 N/m is free to move on a frictionless,
horizontal surface as in the figure below. The block is released
from rest after the spring is stretched a distance A = 0.13 m.
(Indicate the direction with the sign of your answer. Assume that
the positive direction is to the right.)
(a) At that instant, find the force on the block. N
(b)...
A block of mass m = 0.59 kg is attached to a spring with
force constant 128 N/m is free to move on a frictionless,
horizontal surface as in the figure below. The block is released
from rest after the spring is stretched a distance A = 0.13
m. (Indicate the direction with the sign of your answer. Assume
that the positive direction is to the right.) (a) At that instant,
find the force on the block. N (b) At that...
A block of mass m = 0.672 kg is fastened to an unstrained horizontal spring whose spring constant is k = 97.0 N/m. The block is given a displacement of +0.162 m, where the + sign indicates that the displacement is along the +x axis, and then released from rest. (a) What is the force (with sign) that the spring exerts on the block just before the block is released? (b) Find the angular frequency of the resulting oscillatory motion....
A 0.66 kg block attached to a spring with force constant 150 N/m
is free to move on a frictionless, horizontal surface as in the
figure below. The block is released from rest after the spring is
stretched 0.13 m.
(a) At that instant, find the force on the block.
N?
(b) At that instant, find its acceleration.
m/s^2?
A 0.73 kg block on a horizontal frictionless surface is attached to a spring whose force constant is 210 N/m. The block is pulled from its equilibrium position at x = 0 m to a displacement x = +0.080 m and is released from rest. The block then executes simple harmonic motion along the x-axis (horizontal). When the displacement is x = -2.8×10−2 m, the magnitude of the acceleration of the block is closest to: A 0.73 block on a horizontal...
2) A 0.39 Kg is block attached to an ideal spring of force constant (spring constant) 15 N/m executes simple harmonic motion on a frictionless horizontal surface. At time t = 0 s, the block has a displacement of 0.90 m. a) What is the frequency of the oscillations of the cart? (b) Determine the maximum speed of the cart. Where does the maximum speed occur? (c) Find the maximum acceleration of the mass. Where does the maximum acceleration occur?...
A 2.0 kg block on a horizontal frictionless surface is attached to a spring whose force constant is 300 N/m. The block is pulled from its equilibrium position at x = 0 m to a displacement x = + 0.090 m and released from rest t=0 The block then executes SHM along the x-axis horizontal. (a) What is the maximum acceleration and velocity?
A 2.2 kg block executes SHM while attached to a horizontal spring of spring constant 110 N/m. The maximum speed of the block as it slides on a horizontal frictionless surface is 3.9 m/s. What are (a) the amplitude of the block's motion, (b) the magnitude of its maximum acceleration, and (c) the magnitude of its minimum acceleration? (d) How long does the block take to complete 3.3 cycles of its motion?
A block of mass m = 6.14 kg is attached to a spring with spring constant k = 1682 N/m and rests on a frictionless surface. The block is pulled, stretching the spring a distance of 0.135 m, and is held still. The block is then released and moves in simple harmonic motion about the equilibrium position. (Assume that the block is stretched in the positive direction.) (b) Where is the block located 3.24 s after it is released? (Give...
