Enter Shift Alt Power System I Quiz 2 Name Problem 1 (40 points) The field and...
Q1: (30 points) A shunt DC generator, running at a constant speed of 1400 rpm, has...
Q1: (30 points) A shunt DC generator, running at a constant speed of 1400 rpm, has a field resistance of 200 22 and armature resistance of 0.5 12. Ignore armature reaction and assume a 400 W rotational loss. a) [15] While supplying no load, the induced armature voltage is 280 V. Calculate the input power. b) [15] When the generator is loaded, the developed power is found to be 4.1 kW at the same magnetic flux of the field found...
QUESTION 1 A) (10 marks) A 10 kW, 250 V DC self-excited shunt generator, with an...
QUESTION 1 A) (10 marks) A 10 kW, 250 V DC self-excited shunt generator, with an armature resistance of 0.1 ohm, is delivering 80 % of rated power to the mains at rated voltage when being run at 1000 r.p.m. (revolutions per minute). The field circuit resistance is 220 ohms. The brush contact drop is 0.5 V and rotational (mechanical) losses are 750 W Calculate The induced voltage The electromagnetic torque developed The shaft torque The overall efficiency B) (15...
A) The input current to a 220 V, short-shunt compound motor at no load is 6 A. The shunt- field c...
a) The input current to a 220 V, short-shunt compound motor at no load is 6 A. The shunt- field circuit resistance is 220 Ω; the armature resistance is 0.112, and the series-field resistance is 0.1 Ω, what is the stray power loss ? (b) Assume the input rating of the motor in Part (a) to be 66 A at 220 V with a no-load speed of 1000 rpm. If the stray power loss varies as the counter-electromotive force and...
1. A 300 V compound motor has armature resistance 0.18 Ω, series field resistance 0.3 Ω...
1. A 300 V compound motor has armature resistance 0.18 Ω, series field resistance 0.3 Ω and shunt field resistance 100 Ω. The rotational losses are 200 W. On full load the line current is 25 A and the motor runs at 1800 rpm. Determine: (i) the developed mechanical power (ii) the output power (iii) the output torque (iv) the efficiency at full load 2. A 120 V series motor has 0.2 Ω field resistance. On full load, the line...
3. A 25-kW, 230-V shunt motor has an armature resistance of 0.064 Ω and a field-circuit...
3. A 25-kW, 230-V shunt motor has an armature resistance of 0.064 Ω and a field-circuit resistance of 95 Ω. The motor delivers rated output power at rated voltage when its armature current is 122 A. When the motor is operating at rated voltage, the speed is observed to be 1150 r/min when the machine is loaded such that the armature current is 69.5 A a. Calculate the rated-load speed of this motor In order to protect both the motor...
1. Name the various parts of a DC machine and give their function. 2. A four-pole...
1. Name the various parts of a DC machine and give their function. 2. A four-pole de machine with a lap wound armature has a total of 652 armature conductors with an armature resistance of 0.1502. When run as a generator on open circuit at a speed of 400rpm, the armature terminal voltage is 262V. Each pole shoe arc has a diameter of 42cm, subtends an angle of 60° and has an axial length of 20cm. 2.1.Calculate the useful flux...
Hi. please take your time to answer all parts of this question in great detail, please...
Hi.
please take your time to answer all parts of this question in great
detail, please do not assume i know any shorthand on this question
because i do not. Please number all parts as you answer each
question and be as neat as possible and show all formulas and
calculations used as clear as possible, and please label the
diagram too.
Thanks in advance.
a) Draw the equivalent circuit of a shunt-wound DC motor, and write down its governing...
Problem #1 Part I (50 points) Consider the following one-line diagram of a three-phase power system. Assume that the system has the following base quantities: S3 100 MVA, and VbaselL 38 kV at the...
Problem #1 Part I (50 points) Consider the following one-line diagram of a three-phase power system. Assume that the system has the following base quantities: S3 100 MVA, and VbaselL 38 kV at the generator side. The rated line-to-line terminal voltage of the generator (BUS 1) is 38 kV. A single-circuit three-phase transposed overhead line composed by one ACSR Partridge conductor per phase with vertical configuration. The transmission line length is 50 km and the distance between phases a-b, b-c...
(might be 1 or 2, MCQ questions were having images given with them, which we couldn't...
(might be 1 or 2, MCQ questions were having images given with them, which we couldn't insert, so ignore those questions if you cannot answer, sorry for inconveinience created, i tried to delete them but might be couldn't done all) 3) Single phase induction motors work because: a) The oscillating magnetic field can induce starting torque in a rotor. b) The oscillating magnetic field can induce running torque in a rotor. c) A capacitance or inductance can create the phase...
Q1: (30 points) A shunt DC generator, running at a constant speed of 1400 rpm, has a field resistance of 200 22 and armature resistance of 0.5 12. Ignore armature reaction and assume a 400 W rotational loss. a) [15] While supplying no load, the induced armature voltage is 280 V. Calculate the input power. b) [15] When the generator is loaded, the developed power is found to be 4.1 kW at the same magnetic flux of the field found...
QUESTION 1 A) (10 marks) A 10 kW, 250 V DC self-excited shunt generator, with an armature resistance of 0.1 ohm, is delivering 80 % of rated power to the mains at rated voltage when being run at 1000 r.p.m. (revolutions per minute). The field circuit resistance is 220 ohms. The brush contact drop is 0.5 V and rotational (mechanical) losses are 750 W Calculate The induced voltage The electromagnetic torque developed The shaft torque The overall efficiency B) (15...
a) The input current to a 220 V, short-shunt compound motor at no load is 6 A. The shunt- field circuit resistance is 220 Ω; the armature resistance is 0.112, and the series-field resistance is 0.1 Ω, what is the stray power loss ? (b) Assume the input rating of the motor in Part (a) to be 66 A at 220 V with a no-load speed of 1000 rpm. If the stray power loss varies as the counter-electromotive force and...
3. A 25-kW, 230-V shunt motor has an armature resistance of 0.064 Ω and a field-circuit resistance of 95 Ω. The motor delivers rated output power at rated voltage when its armature current is 122 A. When the motor is operating at rated voltage, the speed is observed to be 1150 r/min when the machine is loaded such that the armature current is 69.5 A a. Calculate the rated-load speed of this motor In order to protect both the motor...
1. Name the various parts of a DC machine and give their function. 2. A four-pole de machine with a lap wound armature has a total of 652 armature conductors with an armature resistance of 0.1502. When run as a generator on open circuit at a speed of 400rpm, the armature terminal voltage is 262V. Each pole shoe arc has a diameter of 42cm, subtends an angle of 60° and has an axial length of 20cm. 2.1.Calculate the useful flux...
Hi.
please take your time to answer all parts of this question in great
detail, please do not assume i know any shorthand on this question
because i do not. Please number all parts as you answer each
question and be as neat as possible and show all formulas and
calculations used as clear as possible, and please label the
diagram too.
Thanks in advance.
a) Draw the equivalent circuit of a shunt-wound DC motor, and write down its governing...
Problem #1 Part I (50 points) Consider the following one-line diagram of a three-phase power system. Assume that the system has the following base quantities: S3 100 MVA, and VbaselL 38 kV at the generator side. The rated line-to-line terminal voltage of the generator (BUS 1) is 38 kV. A single-circuit three-phase transposed overhead line composed by one ACSR Partridge conductor per phase with vertical configuration. The transmission line length is 50 km and the distance between phases a-b, b-c...
