4)two capacitors of 1.5 and 0.5 micro F, respectively, are connected in series. The system is...
4)two capacitors of 1.5 and 0.5 micro F, respectively, are connected in series. The system is connected to a 50 V battery. What is the charge accumulated on the 0.5 micro F capacitors?
a- 10.7micro F
b- 25 Micro F
c-18.8 micro F
d-100Micro F
11) Ahigh voltage transmission line of diameter 2cm and length 18 km carries a steady current of 100A. if the conductor is copper with free charge density of 8*1028electrons/m3. Approximatly, how long does it take one electron to travel the full lengh of the cable?(e=1.6*10-19C)
a-200 hours
b-2000 hours
c-20000 hours
d200000 hours
