A closed tank is filled with gasoline at 60 °F. The tank is pressurized and the...
-
A closed tank is filled with gasoline at 60 °F. The tank is pressurized and the pressure at the top of the tank is 10 psi. If the tank is 10 feet tall, what is the pressure at the bottom of the tank? Express your answer in terms of absolute and gage pressure.
Homework Answers
Add Answer to:
A closed tank is filled with gasoline at 60 °F. The tank is
pressurized and the...
Part A : A storage tank 28 m high is filled with gasoline. (Assume the tank...
Part A : A storage tank 28 m high is filled with gasoline. (Assume the tank is open and exposed to the atmosphere at the top.) (a) Find the gauge pressure at the bottom of the tank.( answer in Pa ) (b) Calculate the magnitude of the net force that acts on a square access hatch at the bottom of the tank that measures 0.6 m by 0.6 m.(answer in N ) Part B : What substance is it, most...
please show all work Question 22 0/20p A sealed tank shown below, has a pocket of...
please show all work
Question 22 0/20p A sealed tank shown below, has a pocket of trapped air above the water with a pressure P: (ps. The alr pocket ishin height (50 feet) as shown where as the water level is h in height(40 feet). A pressure gage at the bottom of the tank reads p2(60 psi) and the stand pipe for the entire tank reads hy(feet) Please take your decimals out to two places. (Do not write the units...
A closed tank is filled with water and has a 4-ft-diameter hemispherical dome as shown in...
A closed tank is filled with water and has a 4-ft-diameter
hemispherical dome as shown in the figure below. A U-tube manometer
is connected to the tank. Determine the vertical force of the water
on the dome if the differential manometer reading is 7 ft and the
air pressure at the upper end of the manometer is 13.6 psi.
Setting up the manometer equation, I found the pressure in the
closed tank to be 2894.4 lb/ft^2, but when doing the...
A closed tank contains a fluid whose density is p. The depth of the fluid is...
A closed tank contains a fluid whose density is p. The depth of the fluid is h and the area of the bottom is A. The tank is pressurized, so that the pressure at the top of the tank is Po. The pressure at the bottom of the tank is 4Po. What is the density of the fluid? P h р O 3P./(gh) Ο Ρ Α O 4P0/(gh) 3gh/P
10 points. 1) A closed tank is partially filled with glycerin. If the air pressure in...
10 points. 1) A closed tank is partially filled with glycerin. If the air pressure in the tank is 8 lb/in2 and the depth of glycerin is 12 ft, what is the pressure in lb/ft? at the bottom of the tank? (y = 78.6 lb/ft).
Q3) An inclined manometer tube is connected to two closed tanks as shown in the figure...
Q3) An inclined manometer tube is connected to two closed tanks as shown in the figure below where !-210 cm. A gage was used to measure the pressure at the center of tank A and the reading was 60 kPa. A barometer locates near the tanks reads 72 cm of mercury. Specific weight of water is 9.81 kN/m3 and specific gravity (SG) of mercury is 13.6. a) Find the gage pressure in the center of tank B. b) Find the...
A 80.00 L fuel tank is filled with gasoline on a -10 C day, then rolled...
A 80.00 L fuel tank is filled with gasoline on a -10 C day, then rolled into a storage shed where the temperature is 20° C Part A If the tank is not vented, what minimum volume needs to be left empty at filling time so that the tank doesn't rupture as it warms? Express your answer with the appropriate units | Δν- alue Units
A pressurized water tank contains water with a mass density of 62.1 lbm/ft3. The water depth...
A pressurized water tank contains water with a mass density of 62.1 lbm/ft3. The water depth is 10 feet (above ground level) and the tank is pressurized to 28 psia. The tank outlet at ground level is a 4 inch diameter pipe with a closed valve. Atmospheric pressure is at 14.5 psia. If the valve on the 4 inch pipe is opened all the way what will be the initial water flow rate out of the pipe in ft3/s?
8. A conical storage tank is being filled at a rate of 60 ft./minute. If the...
8. A conical storage tank is being filled at a rate of 60 ft./minute. If the top of the tank is 10 feet in diameter and the depth is 50 feet, at what rate is the radius changing after 3 minutes? V = 1/3 Tr?h. (6 points)
please show all work
Question 22 0/20p A sealed tank shown below, has a pocket of trapped air above the water with a pressure P: (ps. The alr pocket ishin height (50 feet) as shown where as the water level is h in height(40 feet). A pressure gage at the bottom of the tank reads p2(60 psi) and the stand pipe for the entire tank reads hy(feet) Please take your decimals out to two places. (Do not write the units...
A closed tank is filled with water and has a 4-ft-diameter
hemispherical dome as shown in the figure below. A U-tube manometer
is connected to the tank. Determine the vertical force of the water
on the dome if the differential manometer reading is 7 ft and the
air pressure at the upper end of the manometer is 13.6 psi.
Setting up the manometer equation, I found the pressure in the
closed tank to be 2894.4 lb/ft^2, but when doing the...
A closed tank contains a fluid whose density is p. The depth of the fluid is h and the area of the bottom is A. The tank is pressurized, so that the pressure at the top of the tank is Po. The pressure at the bottom of the tank is 4Po. What is the density of the fluid? P h р O 3P./(gh) Ο Ρ Α O 4P0/(gh) 3gh/P
10 points. 1) A closed tank is partially filled with glycerin. If the air pressure in the tank is 8 lb/in2 and the depth of glycerin is 12 ft, what is the pressure in lb/ft? at the bottom of the tank? (y = 78.6 lb/ft).
Q3) An inclined manometer tube is connected to two closed tanks as shown in the figure below where !-210 cm. A gage was used to measure the pressure at the center of tank A and the reading was 60 kPa. A barometer locates near the tanks reads 72 cm of mercury. Specific weight of water is 9.81 kN/m3 and specific gravity (SG) of mercury is 13.6. a) Find the gage pressure in the center of tank B. b) Find the...
A 80.00 L fuel tank is filled with gasoline on a -10 C day, then rolled into a storage shed where the temperature is 20° C Part A If the tank is not vented, what minimum volume needs to be left empty at filling time so that the tank doesn't rupture as it warms? Express your answer with the appropriate units | Δν- alue Units
8. A conical storage tank is being filled at a rate of 60 ft./minute. If the top of the tank is 10 feet in diameter and the depth is 50 feet, at what rate is the radius changing after 3 minutes? V = 1/3 Tr?h. (6 points)
