In class I showed the resonance structures of p-methoxyphenoxide. Provide resonance structures for the following (see...

Question

Question

In class I showed the resonance structures of p-methoxyphenoxide. Provide resonance structures for the following (see section 21.4B for help!):

a. o-methoxyphenoxide

b. m-methoxyphenoxide

c. p-nitrophenoxide

d. m-nitrophenoxide

e. o-nitrophenoxide

science chemistry

Answer 1

Answer #1

0-CH CH İS.nk. ed Mon e Pnecie r , an oPPU . 0 0 niHuo ?heide 0 0 0 0nl

Answer 2
