A motel in Miami, Florida has a sensible cooling load of 75 tons and a sensible...
A motel in Miami, Florida has a sensible cooling load of 75 tons and a sensible heat ratio on the building of 0.85. Each of the motel's 100 rooms must be supplied with 30 cfm of outside air to satisfy the local ventilation codes. If the rooms are kept at 75F and 50% R.H., determine:
a.) sketch of the system
b.) Air flow to the building in cfm (fan size)
c.) The mixed air condition-temperature and humidity
d.) The cooling coil load in tons of A/C
e.) The apparatus Dew Point for the cooling coil
f.) The SHR for the cooling coil
g.) The condensate flow off the the cooling coil at peak design conditions in GPM with 1 gallon of water weighing 8.3 pounds.
Homework Answers
Add Answer to:
A motel in Miami, Florida has a sensible cooling load of 75 tons
and a sensible...
