Q.14 If a copper wire has a radius = 1.0 mm and has a 0.23 V/m electric field strength along its length. Find the current carried by the wire.

science Advanced-Physics

Answer 1

Answer #1

I will be glad to see your comment if you have any query and thumb up if you are satisfied. Thanks !

Answer 2
