Question

Times New 12 S. The igures below show readings of a micrometer, Figure (8.a) shows the zero error reading, Figure (3.b) the reading when the micrometer is being used to measure the diameter of a ball. What is the actual diameter of the ball? (include the units in parenthesis). St 0 Figure 3.a Figure 3.b Zero Reading Reading of sleeve Reading of thimble Total reading of the micrometer Actual diameter of the ball 4 5 7 8 9

0 0
Add a comment Improve this question Transcribed image text
Answer #1

1. Zero reading = 0.005mm

It is 1/200=0.005 and the units are mm since it is a micrometer.

2.Reading of sleeve=5mm

Reading of sleeve is the value before the 0 in the circular scale.

3.Reading of Thimble= 14mm

Reading of thimble is the reading on the screw rotated.

4. Total reading of the micrometer= 5+14*0.01=5.14mm

Total reading is calculated by Main scale reading + Circular scale reading *least count

5. Actual diametre of the ball = 14mm
