Question 4 1.5 pts Three 38-2 lightbulbs and three 71-2 lightbulbs are connected in series. What...
Exercise 3: (1.5 pts) A capacitor of capacitance 0.01 uF is connected to a DC voltage...
Exercise 3: (1.5 pts) A capacitor of capacitance 0.01 uF is connected to a DC voltage source of emf s. When the capacitor becomes fully charged, the battery is removed from the circuit and the capacitor is connected to a resistor of resistance R. What is the resistance R if the charge reaches 25% of its initial value in 2 ms?
Question 19 (9 points) Three 2 V cells are connected in series. This circuit has two...
Question 19 (9 points) Three 2 V cells are connected in series. This circuit has two resistors in parallel. The first resistor is 2 ohms and the second resistor is 4 ohms. What is the voltage of the second resistor? What is the total resistance in the circuit? What is the amperage of each of the resistors? What is the total amperage of the circuit?
2 pts Question 5 Three capacitors are connected as shown in the figure. What is the...
2 pts Question 5 Three capacitors are connected as shown in the figure. What is the equivalent capacitance between points a and b? 2.0F 4.0 MF 6.0 F be O 7.1 uF O 4.0uF 12 JF O 1.7 uF O 8.0 pF
Question 16 1 pts A 50-2 resistor, a 0.1-H inductor, and a 10-uF capacitor are connected...
Question 16 1 pts A 50-2 resistor, a 0.1-H inductor, and a 10-uF capacitor are connected in series to a 60-Hz source. The rms current in the circuit is 3 A. Find the rms voltage across the resistor, the inductor, and the capacitor. O 60 V, 80 V,796 V (all rms) O 150 V, 113V,562 V (allrms) O 150 V, 113 V, 796 V (all rms) O 0.06 V, 80 V,562 V (all rms) 1 pts Question 17 In an...
Really need help with both please u Question 43 2 pts rms The rms voltage across...
Really need help with both please
u Question 43 2 pts rms The rms voltage across and the rms current through a single circuit element connected to an ac generator are, respectively, v = 109 volts and Irms = 39 A. The angular frequency of the generator id w = 60. It is observed that the current leads the voltage by 90°. The element that is connected to the ac generator is either a capacitor, an inductor, or a resistor...
4) Midterm question Problem 2 (30 points) C=30 uF The air capacitors with C=Cq=3.0 MF, C=2.04F...
4) Midterm question Problem 2 (30 points) C=30 uF The air capacitors with C=Cq=3.0 MF, C=2.04F and C3= 1.0F are connected to a Vo battery as shown. If the charge on C2 is Q2=20.0 C, | ,2015 Foton C1.0 F (a) (15 pts. Find the equivalent capacitance of the circuit. (b) (15 pts.) Find V. 1) A charge Q is placed on a capacitor of capacitance C=C. The capacitor is then, connected to a resistor and another capacitor of capacitance...
ANSWER ALL PLEASE Question 43 2 pts The rms voltage across and the rms current through...
ANSWER ALL PLEASE
Question 43 2 pts The rms voltage across and the rms current through a single circuit element connected to an ac generator are, respectively, Vrms = 131 volts and Ims = 37 A. The angular frequency of the generator id w = 78. It is observed that the current leads the voltage by 90°. The element that is connected to the ac generator is either a capacitor, an inductor, or a resistor (only one of the three)....
Engineering circuit analysis by Hayt 8th edition question 27 and figure 9.43 I think 10u(1-t) means 10 (for t<1)...
Engineering circuit analysis by Hayt
8th edition
question 27 and figure 9.43
I think 10u(1-t) means 10 (for t<1) and 0
(for t>1)
then, I can't remove this current source because it
continuously make 10micro A
(at t=500ms, t=1.002ms)
I don't know what's wrong now..
366 26. For the circuit of Fig. 9,43, 1 30-) mA. (a) Select R, so th O)6 V (b) Compute e2 ms). (c) Determine the settling, time of t capacitor voltage. (d) Is the inductor...
ANSWER ALL PLEASE Question 35 2 pts A charged particle (with q = 1.0 x 10-2...
ANSWER ALL PLEASE
Question 35 2 pts A charged particle (with q = 1.0 x 10-2 C) that is moving through a uniform magnetic field has a velocity v = (6.0 x 105m/s) i + (4.0 x 105m/s) k when it experiences a force F due to the magnetic field. If B = (-3.0 x 10-3T)i + (4.0 x 10-3T)j + (5.0 x 10-3T)k, calculate the force, in N (in terms of unit vectors). Equation: F=qvxB OF=-(3.0 N)i - (6.0N)j...
32. A transformer is to be designed to increase the 30 kV-rms output of a generator...
32. A transformer is to be designed to increase the 30 kV-rms output of a generator to the transmission-line voltage of 345 kV-om. If the primary winding has 80 turns, how many turns must the secondary have? b. 70 c. 920 d. 9200 e 12 33. The primary winding of an electric train transformer has 400 turns and the Secondary has 50. If the input voltage is 120V(rms) what is the output voltage? a. 15 V (rms) b. 30 Vrms)...
Exercise 3: (1.5 pts) A capacitor of capacitance 0.01 uF is connected to a DC voltage source of emf s. When the capacitor becomes fully charged, the battery is removed from the circuit and the capacitor is connected to a resistor of resistance R. What is the resistance R if the charge reaches 25% of its initial value in 2 ms?
Question 19 (9 points) Three 2 V cells are connected in series. This circuit has two resistors in parallel. The first resistor is 2 ohms and the second resistor is 4 ohms. What is the voltage of the second resistor? What is the total resistance in the circuit? What is the amperage of each of the resistors? What is the total amperage of the circuit?
2 pts Question 5 Three capacitors are connected as shown in the figure. What is the equivalent capacitance between points a and b? 2.0F 4.0 MF 6.0 F be O 7.1 uF O 4.0uF 12 JF O 1.7 uF O 8.0 pF
Question 16 1 pts A 50-2 resistor, a 0.1-H inductor, and a 10-uF capacitor are connected in series to a 60-Hz source. The rms current in the circuit is 3 A. Find the rms voltage across the resistor, the inductor, and the capacitor. O 60 V, 80 V,796 V (all rms) O 150 V, 113V,562 V (allrms) O 150 V, 113 V, 796 V (all rms) O 0.06 V, 80 V,562 V (all rms) 1 pts Question 17 In an...
Really need help with both please
u Question 43 2 pts rms The rms voltage across and the rms current through a single circuit element connected to an ac generator are, respectively, v = 109 volts and Irms = 39 A. The angular frequency of the generator id w = 60. It is observed that the current leads the voltage by 90°. The element that is connected to the ac generator is either a capacitor, an inductor, or a resistor...
4) Midterm question Problem 2 (30 points) C=30 uF The air capacitors with C=Cq=3.0 MF, C=2.04F and C3= 1.0F are connected to a Vo battery as shown. If the charge on C2 is Q2=20.0 C, | ,2015 Foton C1.0 F (a) (15 pts. Find the equivalent capacitance of the circuit. (b) (15 pts.) Find V. 1) A charge Q is placed on a capacitor of capacitance C=C. The capacitor is then, connected to a resistor and another capacitor of capacitance...
ANSWER ALL PLEASE
Question 43 2 pts The rms voltage across and the rms current through a single circuit element connected to an ac generator are, respectively, Vrms = 131 volts and Ims = 37 A. The angular frequency of the generator id w = 78. It is observed that the current leads the voltage by 90°. The element that is connected to the ac generator is either a capacitor, an inductor, or a resistor (only one of the three)....
Engineering circuit analysis by Hayt
8th edition
question 27 and figure 9.43
I think 10u(1-t) means 10 (for t<1) and 0
(for t>1)
then, I can't remove this current source because it
continuously make 10micro A
(at t=500ms, t=1.002ms)
I don't know what's wrong now..
366 26. For the circuit of Fig. 9,43, 1 30-) mA. (a) Select R, so th O)6 V (b) Compute e2 ms). (c) Determine the settling, time of t capacitor voltage. (d) Is the inductor...
ANSWER ALL PLEASE
Question 35 2 pts A charged particle (with q = 1.0 x 10-2 C) that is moving through a uniform magnetic field has a velocity v = (6.0 x 105m/s) i + (4.0 x 105m/s) k when it experiences a force F due to the magnetic field. If B = (-3.0 x 10-3T)i + (4.0 x 10-3T)j + (5.0 x 10-3T)k, calculate the force, in N (in terms of unit vectors). Equation: F=qvxB OF=-(3.0 N)i - (6.0N)j...
32. A transformer is to be designed to increase the 30 kV-rms output of a generator to the transmission-line voltage of 345 kV-om. If the primary winding has 80 turns, how many turns must the secondary have? b. 70 c. 920 d. 9200 e 12 33. The primary winding of an electric train transformer has 400 turns and the Secondary has 50. If the input voltage is 120V(rms) what is the output voltage? a. 15 V (rms) b. 30 Vrms)...
