A long steel bar with a diameter of 4 cm (ρ = 7840 kg / m3...
A long steel bar with a diameter of 4 cm (ρ = 7840 kg / m3 , cp = 580 J / kg ° K, k = 52 W / mK, α = 1.21x10-5 m2 / s), internal enters the 2 m long moving belt heat treatment furnace at ambient temperature of 900 ° C at 40 ° C. Since the film coefficient in the oven is 100 W / m2K, the center axis temperature of the bar at the oven exit is 60 ° C. in order to be
a.) Find the elapsed time.
b.) Find the transition speed (band speed) of the steel rod.
Homework Answers
