A binary waveform with a bit rate of 5818 bits/sec is passed through a system with...
A binary waveform with a bit rate of 5818 bits/sec is passed through a system with equivalent transfer function given by the raised cosine Nyquist filter with cutoff 5269 Hz. What is the rolloff factor, r, of the raised cosine filter?
State your answer to two decimal places.
