You're riding a bicycle on level ground and begin to apply the brakes. This applies a...
You're riding a bicycle on level ground and begin to apply the brakes. This applies a force friction Ff to your wheel at a distance of 41.5cm from the axis. You begin to slow down at a constant rate of 3.83m/s^2. If the wheel has a radius of 0.68m and a mass of 0.91kg, what is the magnitude of Ff? Use the approximation that a bicycle wheel has a moment of inertia I=MR^2.
Homework Answers
Add Answer to:
You're riding a bicycle on level ground and begin to apply the
brakes. This applies a...
A bicycle wheel with a radius of 0.40 meters has a mass of 2.25 kg mostly...
A bicycle wheel with a radius of 0.40 meters has a mass of 2.25 kg mostly :concentrated near the rim. Treat the wheel as a ring of mass, I_ring = m r^2, rotating at 146 rpm (15.3 rad/s). Brakes on the rim slow the wheel to a stop at a constant angu acceleration. the angular acceleration, a, of the wheel if it is brought to rest in 5 seconds is the moment of inertia of the wheel, I, is closest...
A stationary bicycle is raised off the ground, and its front wheel (m = 1.3 kg)...
A stationary bicycle is raised off the ground, and its front wheel (m = 1.3 kg) is rotating at an angular velocity of 14.2 rad/s (see the drawing). The front brake is then applied for 3.0 s, and the wheel slows down to 3.2 rad/s. Assume that all the mass of the wheel is concentrated in the rim, the radius of which is 0.34 m. The coefficient of kinetic friction between each brake pad and the rim is μk =...
A stationary bicycle is raised off the ground, and its front wheel (m = 1.44 kg)...
A stationary bicycle is raised off the ground, and its front wheel (m = 1.44 kg) is rotating at an angular velocity of 20.8 rad/s (see the figure). The front brake is then applied for 2.83 s, and the wheel slows down to 2.08 rad/s. Assume that all the mass of the wheel is concentrated in the rim, the radius of which is 0.330 m. The coefficient of kinetic friction between each brake pad and the rim is μk =...
The lightweight wheel on a road bike has a moment of inertia of 0.097 kg⋅ m...
The lightweight wheel on a road bike has a moment of inertia of 0.097 kg⋅ m 2 . A mechanic, checking the alignment of the wheel, gives it a quick spin; it completes 5 rotations in 2 s . To bring the wheel to rest, the mechanic gently applies the disk brakes, which squeeze pads against a metal disk connected to the wheel. The pads touch the disk 7.1 cm from the axle, and the wheel slows down and stops...
The lightweight wheel on a road bike has a moment of inertia of 0.097 kg⋅ m...
The lightweight wheel on a road bike has a moment of inertia of 0.097 kg⋅ m 2 . A mechanic, checking the alignment of the wheel, gives it a quick spin; it completes 5 rotations in 2 s . To bring the wheel to rest, the mechanic gently applies the disk brakes, which squeeze pads against a metal disk connected to the wheel. The pads touch the disk 7.1 cm from the axle, and the wheel slows down and stops...
A bicycle wheel is mounted on a fixed, frictionless axle, with alight string wound around its rim. The wheel has moment...
A bicycle wheel is mounted on a fixed, frictionless axle, with alight string wound around its rim. The wheel has moment of inertia I=kmr2, where m is its mass, r is its radius, and k is a dimensionless constant between zero and one. The wheel is rotating counterclockwise with angular velocity w0, when at time t=0 someone starts pulling the string with a force of magnitude F. Assume that the string does not slip on the wheel.Part ASuppose that after a certain time tL,...
PHY 121 Homework 12 Due: Thursday, November 21" Physics 121 Homework 12 1) You are riding a bike at a speed of 4.3...
PHY 121 Homework 12 Due: Thursday, November 21" Physics 121 Homework 12 1) You are riding a bike at a speed of 4.3 m/s. You apply the rear brakes and come to a stop in 4 seconds. The moment of inertia of the rear bike wheel is 0.15 kg.m', and its radius is 0.33 m. If the rear wheel is rolling without slipping, what was the average torque exerted on it during the 4 seconds that you applied the brakes?...
A playground merry-go-round has a radius of R = 4.0m and has a moment of inertia...
A playground merry-go-round has a radius of R = 4.0m and has a moment of inertia I_cm = 7.0 times 10^3 kg middot m^2 about an axis passing through the center of mass. There is negligible friction about its vertical axis. Two children each of mass m = 25kg are standing on opposite sides a distance r_0 = 3.0m from the central axis. The merry-go-round is initially at rest. A person on the ground applies a constant tangential force of...
The car shown in the figure has mass m(this includes the mass of the wheels). The wheels have radius r, mass mw, and m...
The car shown in the figure has mass m(this includes
the mass of the wheels). The wheels have radius r, mass
mw, and moment of inertia
I=kmwr2. Assume that the axles
apply the same torque ? to all four wheels. For
simplicity, also assume that the weight is distributed uniformly so
that all the wheels experience the same normal reaction from the
ground, and so the same frictional force.
Part A
If there is no slipping, a frictional force must...
A bicycle wheel with a radius of 0.40 meters has a mass of 2.25 kg mostly :concentrated near the rim. Treat the wheel as a ring of mass, I_ring = m r^2, rotating at 146 rpm (15.3 rad/s). Brakes on the rim slow the wheel to a stop at a constant angu acceleration. the angular acceleration, a, of the wheel if it is brought to rest in 5 seconds is the moment of inertia of the wheel, I, is closest...
PHY 121 Homework 12 Due: Thursday, November 21" Physics 121 Homework 12 1) You are riding a bike at a speed of 4.3 m/s. You apply the rear brakes and come to a stop in 4 seconds. The moment of inertia of the rear bike wheel is 0.15 kg.m', and its radius is 0.33 m. If the rear wheel is rolling without slipping, what was the average torque exerted on it during the 4 seconds that you applied the brakes?...
A playground merry-go-round has a radius of R = 4.0m and has a moment of inertia I_cm = 7.0 times 10^3 kg middot m^2 about an axis passing through the center of mass. There is negligible friction about its vertical axis. Two children each of mass m = 25kg are standing on opposite sides a distance r_0 = 3.0m from the central axis. The merry-go-round is initially at rest. A person on the ground applies a constant tangential force of...
The car shown in the figure has mass m(this includes
the mass of the wheels). The wheels have radius r, mass
mw, and moment of inertia
I=kmwr2. Assume that the axles
apply the same torque ? to all four wheels. For
simplicity, also assume that the weight is distributed uniformly so
that all the wheels experience the same normal reaction from the
ground, and so the same frictional force.
Part A
If there is no slipping, a frictional force must...
