A circuit element has a phasor voltage of V = 256 30◦ and a current of...

A circuit element has a phasor voltage of V = 256 30◦ and a current of I = 2.56 (−60)◦ . The angular frequency is 25 rad/s. Decide on whether the circuit element is a capacitor or an inductor. If it is a capacitor, give its capacitance in microFarads (µF); if it is an inductor, give its inductance in Henrys (H).

engineering   Electrical-Engineering
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A circuit element has a phasor voltage of V = 256 30◦ and a current of...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • An AC circuit has a resistance of 500 ohms, a voltage of 200 V, an inductance...

    An AC circuit has a resistance of 500 ohms, a voltage of 200 V, an inductance of 0.4 mHz, a capacitance of 100pF and an angular frequency of 5.00 x 105 rad/s. What is the impedance? What is the current amplitude? What is the voltage amplitude read by a voltmeter across the inductor, the resistor, and the capacitor individually? What is the voltage amplitude read by a voltmeter across the inductor and capacitor together?

  • An ac generator supplies an rms voltage of 140 V and an rms current of 2.0...

    An ac generator supplies an rms voltage of 140 V and an rms current of 2.0 A at an angular frequency of of 500 rad/s. The generator is connected in series with an inductor, a 200-µF capacitor and an 56-Ω resistor. What is the inductance of the inductor?

  • Part A: What is the impedance of the circuit? Part B: What is the current amplitude?...

    Part A: What is the impedance of the circuit? Part B: What is the current amplitude? Part C: What is the phase angle of the source voltage with respect to the current? Part D: Does the source voltage lag or lead the current? Part E: What is the voltage amplitude across the resistor? Part F: What is the voltage amplitude across the inductor? Part G: What is the voltage amplitudes across the capacitor? Constants You have a resistor of resistance...

  • In an L-R-C series circuit, the resistance is 380 ohms, the inductance is 0.360 henrys, and...

    In an L-R-C series circuit, the resistance is 380 ohms, the inductance is 0.360 henrys, and the capacitance is 1.40×10−2 microfarads. 1)What is the resonance angular frequency ω0 of the circuit? 2)The capacitor can withstand a peak voltage of 580 volts. If the voltage source operates at the resonance frequency, what maximum voltage amplitude Vmax can the source have if the maximum capacitor voltage is not exceeded?

  • Resonance in an R-L-C Circuit In an L-R-C series circuit, the resistance is 320 ohms, the...

    Resonance in an R-L-C Circuit In an L-R-C series circuit, the resistance is 320 ohms, the inductance is 0.300 henrys, and the capacitance is 1.80x102 microfarads. Part A What is the resonance angular frequency wo of the circuit? Express your answer in radians per second to three significant figures. Vie Available Hint(s) 1.29 10 rad/s wo Previous Answers Submit x Incorrect; Try Again; 5 attempts remaining Part B The capacitor can withstand a peak voltage of 560 volts. If the...

  • A series LRC circuit is driven by an ac source with a voltage amplitude of 36.0...

    A series LRC circuit is driven by an ac source with a voltage amplitude of 36.0 V and a frequency of 60.0 Hz. The resistance is 160 Ohm, the inductance is 0.230 H, and the capacitance is 70.0 mu F. a) Determine the impedance of the circuit. b) Determine the current amplitude. c) Determine the voltage amplitude across (i) the resistor, (ii) the inductor and (iii) the capacitor. d) Sketch the phasor diagram (at t = 0) for the circuit,...

  • In an L-R-C series circuit, the resistance is 340 ohms, the inductance is 0.340 henrys, and...

    In an L-R-C series circuit, the resistance is 340 ohms, the inductance is 0.340 henrys, and the capacitance is 1.40×10−2 microfarads. A) what is the resonance angular frequency ω0 of the circuit? Express your answer in radians per second to three significant figures. B) The capacitor can withstand a peak voltage of 600 volts. If the voltage source operates at the resonance frequency, what maximum voltage amplitude Vmax can the source have if the maximum capacitor voltage is not exceeded?...

  • In an L-R-C series circuit, the resistance is 360 ohms, the inductance is 0.380 henrys, and...

    In an L-R-C series circuit, the resistance is 360 ohms, the inductance is 0.380 henrys, and the capacitance is 2.00×10−2 microfarads. What is the resonance angular frequency ω0 of the circuit? Express your answer in radians per second to three significant figures. The capacitor can withstand a peak voltage of 550 volts. If the voltage source operates at the resonance frequency, what maximum voltage amplitude Vmax can the source have if the maximum capacitor voltage is not exceeded? Express your...

  • If an inductor and a capacitor are in series in a circuit with low resistance, what...

    If an inductor and a capacitor are in series in a circuit with low resistance, what frequency may the circuit "ring" at? This is the frequency of oscillations that will naturally occur and continue once started. Give your answer in kilohertz (1000 Hz) if the inductance is 88 millihenries and the capacitance is 0.05 microfarads. Find the frequency "f", not the angular frequency omega.

  • If an inductor and a capacitor are in series in a circuit with low resistance, what...

    If an inductor and a capacitor are in series in a circuit with low resistance, what frequency may the circuit "ring" at? This is the frequency of oscillations that will naturally occur and continue once started. Give your answer in kilohertz (1000 Hz) if the inductance is 40 millihenries and the capacitance is 0.05 microfarads. Find the frequency "f", not the angular frequency omega.
