A mercury thermometer is constructed as shown. The capillary tube has a diameter of 0.0052 cm,...

A mercury thermometer is constructed as shown. The capillary tube has a diameter of 0.0052 cm, and the bulb has a diameter of 0.3 cm. Neglecting the expansion of the glass, find the change in height of the mercury column for a temperature change of 27 ◦C. The volume expansion coefficient for mercury is 0.000182 (◦C)−1 . Answer in units of cm.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A mercury thermometer is constructed as shown. The capillary tube has a diameter of 0.0052 cm,...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A mercury thermometer consists of a 0.4-mm capillary tube connected to a glass bulb. The mercury...

    A mercury thermometer consists of a 0.4-mm capillary tube connected to a glass bulb. The mercury rises 7.5 cm as the temperature of the thermometer increases from 35°C to 43°C. Find the volume of the thermometer bulb.

  • 9. 0/1 points Previous Answers SerPSE10 18.4.0P.010.MI. My Notes A mercury thermometer is constructed as shown...

    9. 0/1 points Previous Answers SerPSE10 18.4.0P.010.MI. My Notes A mercury thermometer is constructed as shown below. The Pyrex glass capillary tube has a diameter of 0.004 20 cm, and the bulb has a diameter of 0.280 cm. Find the change in height of the mercury column that occurs with a temperature change of 23.0°C. 2.07 Your response differs from the correct answer by more than 10%. Double check your calculations. cm T+AT O Need Help? Read it Master it...

  • Mercury is often used as an expansion medium in a thermometer. The mercury sits in a...

    Mercury is often used as an expansion medium in a thermometer. The mercury sits in a bulb on the bottom of the thermometer and rises up a thin capillary as the temperature rises. Suppose a mercury thermometer contains 3.400 g of mercury and has a capillary that is 0.220 mm in diameter. Part A How far does the mercury rise in the capillary when the temperature changes from 0.0 ∘C to 25.0 ∘C? The density of mercury at these temperatures...

  • A mercury thermometer consists of a glass bulb completely full of mercury. This is connected to...

    A mercury thermometer consists of a glass bulb completely full of mercury. This is connected to an empty vertical glass tube of radius 0.01 cm. If the volume expansivity of mercury is 1.81 10−4 K−1, and the top of the mercury rises 2.3 cm for a 10◦C change in temperature, calculate the volume of the glass bulb. [Assume the expansivity of the glass is negligible when compared with that of the mercury.] Answer: 0.399 cm^3

  • Mercury is often used as an expansion medium in a thermometer. The mercury sits in a...

    Mercury is often used as an expansion medium in a thermometer. The mercury sits in a bulb on the bottom of the thermometer and rises up a thin capillary as the temperature rises. Suppose a mercury thermometer contains 3.400 gg of mercury and has a capillary that is 0.220 mmmm in diameter. How far does the mercury rise in the capillary when the temperature changes from 0.0 ∘C∘C to 25.0 ∘C∘C? The density of mercury at these temperatures is 13.596...

  • A mercury thermometer contains 800 mm3 of mercury. The inside of the thermometer tube has a...

    A mercury thermometer contains 800 mm3 of mercury. The inside of the thermometer tube has a cross-sectional area of 0.50 mm2 . (The volume expansion coefficient for mercury is 1.81×10−4 ∘C−1.) What should the spacing between the ∘C marks be?

  • Can you please help me to resolve this problem? Please provide a detailed explanation on the...

    Can you please help me to resolve this problem? Please provide a detailed explanation on the procedures used to resolve it. Thank you very much!! thermometer at -10.0°C At -10.0°C, mercury in a thermometer completely fills a spherical cavity of radius r = 0.350 cm at the bottom of a glass tube. For mercury, the coefficient of volume expansion (B) is 1.82 10-4/°C. Calculate the increase in volume of the mercury if the temperature rises to +30.0 °C. The diameter...

  • The length or the mercury column in a certain mercury-in-glass thermometer is 5.00 cm when the...

    The length or the mercury column in a certain mercury-in-glass thermometer is 5.00 cm when the thermometer is in contact with water at Its triple point. Consider the length of the mercury column as the thermometric property X and let θ be the empirical temperature determined by this thermometer. a) Calculate the empirical temperature, measured when the length or the mercury column is 6.00 cm. bI Calculate the length or the mercury column at the steam point. c) If X...

  • 1)The length of the column of mercury in a thermometer is 2.5 cm when the thermometer...

    1)The length of the column of mercury in a thermometer is 2.5 cm when the thermometer is immersed in ice water and 23.5 cm when the thermometer is immersed in boiled water. What should be the length at room temperature of 22◦C? Answer in units of cm. 2)If the mercury column is 26.3 cm long when the thermometer is immersed in a chemical solution, what is the temperature of the solution? Answer in units of ◦C.

  • Consider a capillary tube as shown in the figure below. Find the diameter of the tube...

    Consider a capillary tube as shown in the figure below. Find the diameter of the tube if the contact angle = 20° and the height h 15 mm.Take σ' = 0.073 Nim and y-9789 kN/m' Q3. 2mRe, Liquid 2R 0 3 cm Take i 0025 Ni
