Preparing for a test and this question is blank on my study guide, PLZ SHOW STEPS CLEARLY. Thank You!!!

Two point charges are arranged on a coordinate plane as follows: q1 = 3.4 nC (-3.4m, 5.2m) q2 = -6.7nC (2.3m, -1.8m)

1. a) Find the work done to move a particle from q3 = 8.6nC to the origin; b) find the electric potential at the origin.

science physics

Answer 1

Answer #1

Answer 2
