If the carrier wave frequency is 900MHz, and the moving speed of the mobile station is...
Homework Answers
Add Answer to:
If the carrier wave frequency is 900MHz, and the moving speed
of the mobile station is...
A cellular system is operated at a carrier frequency of 1.9 GHz. For a mobile user...
A cellular system is operated at a carrier frequency of 1.9 GHz. For a mobile user traveling at a speed of 100 km/hr (a) Determine the maximum Doppler frequency,fo (b) In what situation, the Doppler frequency would equal to 0 Hz? (c) In what situation, the Doppler frequency would equal to fo2? (d) Assuming that the received power is P, - 0 dBm, draw the baseband power spectrum given below else
. Consider a mobile communication system using a carrier frequency of 900 MHz. A mobile in...
. Consider a mobile communication system using a carrier frequency of 900 MHz. A mobile in this system is travelling at a speed of 40kmph towards the base station in the cell. Calculate the frequency of the received signal. If the mobile user transmits date at rate of 100 Kbps, determine whether the channel is slow or fast fading.
Please only solve for N(R) - the first picture is simply there so you may calculate N(R)
Please only solve for N(R) - the first picture is simply there
so you may calculate N(R)
Assume your car, with Rx antenna perfectly aligned with base station Tx antenna, is moving with speed of 60 Km/hour. Assuming carrier frequency of 10 MEHz, find the Doppler frequency [m/sec]. (3) in IHzl Use f (v) Cos 0 and unit of [m] for ' and 'v' in Per Doppler frequency you found in Problem 2, calculate the Level Crossing Rate (LCR) denoted...
Question 8 Consider a source emitting sound at frequency f. The speed of sound wave in...
Question 8 Consider a source emitting sound at frequency f. The speed of sound wave in the medium is v. (a) Show that the Doppler frequency is for a stationary observer as the source approaches at speed v 12 marks (b) Show that the Doppler frequency is f for a stationary observer as the source recedes at speed v, [2 marks (c) Show that the Doppler frequency is vv as the observer and the source are travelling towards each other...
1) a) What is the maximum Doppler for a vehicle speed of 140 km/hr at 900...
1) a) What is the maximum Doppler for a vehicle speed of 140 km/hr at 900 MHz? b) What is the minimum (most negative) Doppler for this case? c) For this range of Doppler, what is the corresponding speed at 1800 MHz? 2) What is the probability that a Rayleigh faded signal is at least 15 dB lower than its mean power? 3) a) If a vehicle is moving at 140 km/hr and using a 900 MHz carrier, how long...
1. A source moving with a speed 37 m/s, emits a sound wave with a frequency...
1. A source moving with a speed 37 m/s, emits a sound wave with a frequency f = 377 Hz. Determine the frequency detected by a stationary observer if the speed of sound is v = 343 m/s and the source is moving towards the observer. 2.A stationary source, emits a sound wave with a frequency f = 428 Hz. Determine the frequency detected by an observer moving towards the source with a speed v = 43 m/s, if the...
answer the question and write the formula Decide the Rician factor K [dB] for the LOS...
answer the question and write the formula
Decide the Rician factor K [dB] for the LOS power of 10 [m W] and diffuse components power of I [mW1. (2) 1. 10 l k 1699 17 2. Assume your car, with Rx antenna perfectly aligned with base station Tx antenna, is moving with speed ‘v' of 60 Km/hour. Assuming carrier frequency of 100 MHz, find the Doppler frequency in [Hz]. Use a-(va) Cos θ and unit of [m] for' λ, and...
3 questions plzzzzz QUESTION 32 Calculate the frequency of a 2 meter long sound wave as...
3 questions plzzzzz
QUESTION 32 Calculate the frequency of a 2 meter long sound wave as it travels through the air at a speed of 330 m/s. (do not type the units in your answer). QUESTION 33 A wave with a frequency of 5000 Hz is sent into the body and a signal is received back with a frequency of 4910Hz. What is the Doppler shift? (do not type the units) QUESTION 34 A sound wave is ringing at 6...
4. In one of the original Doppler experiments, a tuba was played on a train at a speed of 60 km/h, at a constant frequency of 75 Hz, while a second identical tuba played the same note on the plat...
4. In one of the original Doppler experiments, a tuba was played on a train at a speed of 60 km/h, at a constant frequency of 75 Hz, while a second identical tuba played the same note on the platiorm at the railway station. Assume the observer is standing still on the platiorm on a day when the outside air temperature is 20° C a. What is the effect that is observed regardless of any sound from the tuba at...
An Electromagnetic Wave A sinusoidal electromagnetic wave of frequency 43.0 MHz travels in free space in...
An Electromagnetic Wave A sinusoidal electromagnetic wave of frequency 43.0 MHz travels in free space in the x-direction as in the figure. At some instant, a plane electromagnetic wave moving in the x direction has a maximum electric field of 725 N/C in the positive y direction. (a) Determine the wavelength and period of the wave. SOLUTION plane. Conceptualize Imagine the wave in the figure moving to the right along the x-axis, with the electric and magnetic fields oscillating in...
A cellular system is operated at a carrier frequency of 1.9 GHz. For a mobile user traveling at a speed of 100 km/hr (a) Determine the maximum Doppler frequency,fo (b) In what situation, the Doppler frequency would equal to 0 Hz? (c) In what situation, the Doppler frequency would equal to fo2? (d) Assuming that the received power is P, - 0 dBm, draw the baseband power spectrum given below else
Please only solve for N(R) - the first picture is simply there
so you may calculate N(R)
Assume your car, with Rx antenna perfectly aligned with base station Tx antenna, is moving with speed of 60 Km/hour. Assuming carrier frequency of 10 MEHz, find the Doppler frequency [m/sec]. (3) in IHzl Use f (v) Cos 0 and unit of [m] for ' and 'v' in Per Doppler frequency you found in Problem 2, calculate the Level Crossing Rate (LCR) denoted...
Question 8 Consider a source emitting sound at frequency f. The speed of sound wave in the medium is v. (a) Show that the Doppler frequency is for a stationary observer as the source approaches at speed v 12 marks (b) Show that the Doppler frequency is f for a stationary observer as the source recedes at speed v, [2 marks (c) Show that the Doppler frequency is vv as the observer and the source are travelling towards each other...
answer the question and write the formula
Decide the Rician factor K [dB] for the LOS power of 10 [m W] and diffuse components power of I [mW1. (2) 1. 10 l k 1699 17 2. Assume your car, with Rx antenna perfectly aligned with base station Tx antenna, is moving with speed ‘v' of 60 Km/hour. Assuming carrier frequency of 100 MHz, find the Doppler frequency in [Hz]. Use a-(va) Cos θ and unit of [m] for' λ, and...
3 questions plzzzzz
QUESTION 32 Calculate the frequency of a 2 meter long sound wave as it travels through the air at a speed of 330 m/s. (do not type the units in your answer). QUESTION 33 A wave with a frequency of 5000 Hz is sent into the body and a signal is received back with a frequency of 4910Hz. What is the Doppler shift? (do not type the units) QUESTION 34 A sound wave is ringing at 6...
4. In one of the original Doppler experiments, a tuba was played on a train at a speed of 60 km/h, at a constant frequency of 75 Hz, while a second identical tuba played the same note on the platiorm at the railway station. Assume the observer is standing still on the platiorm on a day when the outside air temperature is 20° C a. What is the effect that is observed regardless of any sound from the tuba at...
An Electromagnetic Wave A sinusoidal electromagnetic wave of frequency 43.0 MHz travels in free space in the x-direction as in the figure. At some instant, a plane electromagnetic wave moving in the x direction has a maximum electric field of 725 N/C in the positive y direction. (a) Determine the wavelength and period of the wave. SOLUTION plane. Conceptualize Imagine the wave in the figure moving to the right along the x-axis, with the electric and magnetic fields oscillating in...
