Question

a regular octahedran is a polyhedron with eight faces, twelve edged, and six vertices. a point...

a regular octahedran is a polyhedron with eight faces, twelve edged, and six vertices. a point charge of +q= 6 nC is placed at the center of this regular octahedron. what is the electric flux through one of the surfaces of this octahedron?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
a regular octahedran is a polyhedron with eight faces, twelve edged, and six vertices. a point...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • Six charges (-q) are placed on the vertices of a regular hexagon with side length R...

    Six charges (-q) are placed on the vertices of a regular hexagon with side length R and a positive charge (+q) is placed at the center. a) What is the magnitude and direction of the net force on the positive charge at the center? Show your work. b) The bottom charge is removed; now what is the net force on the positive charge at the center? Show your work.

  • Eight +2 nC charges are placed on the vertices of a cube. The cube is centered...

    Eight +2 nC charges are placed on the vertices of a cube. The cube is centered at Q = (0, 0, 0) the origin. The (x, y, z) co-ordinates of the vertices are givenby the eight combinations in (±a,±a,±a). If a = 10 cm what is the net electric field at point P = (0, a/2 , 0)? Sketch the situation and state the direction of net electric field at P. What is the electric field at the origin Q?

  • Here is a picture of an octahedron, which is a regular (Platonic) solid with 8 triangular...

    Here is a picture of an octahedron, which is a regular (Platonic) solid with 8 triangular faces, 12 edges, and 6 vertices. You can imagine an octahedron as two pyramids with square bases, which are then glued together along their bases. octahedron We can turn a polyhedron into a graph by placing its vertices in the plane, and adding edges between those vertices which share an edge on the solid. If we do this to the octahedron, we get the...

  • Item 5 raILA What is the electric flux through each of the six faces of the...

    Item 5 raILA What is the electric flux through each of the six faces of the cube? Use eo for the permittivity of free space (not the EMF symbol o Review A point charge of magnitude q is at the center of a cube with sides of length L View Available Hint(s) Submit Part What would be the flux Ф1 through a face of the cube if its sides were of length L? Use eo for the permittivity of free...

  • A point charge 5.50 nC is at the center of a cube with sides of length...

    A point charge 5.50 nC is at the center of a cube with sides of length 0.200 m . a. What is the electric flux through the surface of the cube? Express your answer in newton meters squared per coulomb to three significant figures b. What is the electric flux through one of the six faces of the cube? Express your answer in newton meters squared per coulomb to three significant figures

  • Please use Gauss's law to find the electric flux through one of the three faces of...

    Please use Gauss's law to find the electric flux through one of the three faces of a cube that meet at the corner where a point charge q = 1.062 nC is located.

  • An electric point charge of Q = 13.1 nC is placed at the center of a...

    An electric point charge of Q = 13.1 nC is placed at the center of a sphere with a radius of r = 32.1 cm. The sphere in this question is only a mathematical surface, it is not made out of any physical material. What is the electric flux through the surface of this sphere? Tries 0/12 This same point charge is now moved out from the center of the sphere by a distance of 17.9 cm. What is the...

  • Two -3.00 nC point charges occupy the two lower vertices of a rectangle that is 6.00...

    Two -3.00 nC point charges occupy the two lower vertices of a rectangle that is 6.00 cm wide and 8.00 cm tall. Two -1.00 nC point charges occupy the upper two vertices. Determine the magnitude and direction of the electric field at the center of the rectangle (Answer: 11520 N/C downward) What would be the magnitude and direction of the electric force acting on a -3.00 nC point charge placed at the center of the square? (Answer: 3.46 x 10-5...

  • PRACTICE: A point charge Q is placed at the center of cube of side a. The...

    PRACTICE: A point charge Q is placed at the center of cube of side a. The electric flux through any one of the six sides is a. kQ/a2 b. Q/6ɛo c. Q/ɛo d. O e. Cannot be determined from the information provided a a

  • A point charge of magnitude q is at the center of a cube with sides of...

    A point charge of magnitude q is at the center of a cube with sides of length L Part A) What is the electric flux ? through each of the six faces of the cube? Use ?0 for the permittivity of free space. Part B) What would be the flux ?1 through a face of the cube if its sides were of length L1 ? Use ?0 for the permittivity of free space.
