A horizontal power line carries a current of 5830 A from south to north. Earth's magnetic...

A horizontal power line carries a current of 5830 A from south to north. Earth's magnetic field (85.2 µT) is directed toward the north and is inclined downward at 72.0° to the horizontal. Find the (a) magnitude and (b) direction of the magnetic force on 120 m of the line due to Earth's field.

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A horizontal power line carries a current of 5830 A from south to north. Earth's magnetic...
