A cylinder is 3 cm long and has a diameter of 4 mm. When an electric...

A cylinder is 3 cm long and has a diameter of 4 mm. When an electric potential of 50 V is applied across the ends of the cylinder, it is found to dissipate 2 W of power. What is the resistivity of the material?

science   physics
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
A cylinder is 3 cm long and has a diameter of 4 mm. When an electric...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • A wire 3.66 m long and 6.77 mm in diameter has a resistance of 21.7 m?....

    A wire 3.66 m long and 6.77 mm in diameter has a resistance of 21.7 m?. A potential difference of 17.5 V is applied between the ends. (a) What is the current in amperes in the wire? (b) What is the magnitude of the current density? (c) Calculate the resistivity of the material of which the wire is made. (a) Number Units (b) Number Units (c) Number Units A wire 3.66 m long and 6.77 mm in diameter has a...

  • ОА A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 V is...

    ОА A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 V is applied across the ends of the wire, the current is 0.0833 A. What is the resistivity of the material? 9.71 x 10-80 m ОВ. None of these answers Ос. 3.89 x 10-70m OD 674x 10-100m 1.24 x 1070 m ОЕ

  • QUESTION 20 A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 V...

    QUESTION 20 A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 V is applied across the ends of the wire, the current is 0.0833 A. What is the resistivity of the material? ОА 6.74 x 10-10 m B. 3.89 x 10-70-m Ос. 1.24 x 1070m None of these answers D. E. 9.71 x 10-80-m

  • QUESTION 14 A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 V...

    QUESTION 14 A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 V is applied across the ends of the wire, the current is 0.0833 A. What is the resistivity of the material? 6,74 x 10-100-m ОА. None of these answers ОВ. Ос. 3.89 x 10-70m 9.71 x 10-80-m OD. ОЕ. 1.24 x 10-70-m

  • 15. A spool of aluminum wire 290 m long and with a diameter of 0.440 mm...

    15. A spool of aluminum wire 290 m long and with a diameter of 0.440 mm is at 20.0°C. For aluminum, the resistivity is 2.82 ✕ 10−8 Ω · m and the temperature coefficient of resistivity is 3.90 ✕ 10−3 (°C)−1. (a) What is the magnitude of the electric field (in V/m) in the wire if it carries a current of 0.600 A? V/m (b) What is the electric power (in W) delivered to the spool while it carries a...

  • A wire 3.07 m long and 8.24 mm in diameter has a resistance of 17.2 mΩ....

    A wire 3.07 m long and 8.24 mm in diameter has a resistance of 17.2 mΩ. A potential difference of 27.7 V is applied between the ends. (a) What is the current in amperes in the wire? (b) What is the magnitude of the current density? (c) Calculate the resistivity of the material of which the wire is made.

  • The cylindrical surface of plastic cylinder, 20.0 m long and 2.80 cm in diameter is coated...

    The cylindrical surface of plastic cylinder, 20.0 m long and 2.80 cm in diameter is coated on the outside with a uniform layer of gold, 0.09 mm thick. A voltage source of 12 V is applied across the flat ends. ρgold = 2.44 × 10−8 Ω · m What is the resistance of the coated cylinder?

  • OA ов. Awire 15.0 m long has a diameter of 0.321 mm. When 1.50 Vis applied...

    OA ов. Awire 15.0 m long has a diameter of 0.321 mm. When 1.50 Vis applied across the ends of the wire, the current is 0.0833 A What is the resistivity of the material? 3.89x1070 m 1.24 x 1070 m 9.71 x 10-80-m 6.74 x 10-100-m Ос. OD. ОЕ. None of these answers

  • QUESTION 16 A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 Vis...

    QUESTION 16 A wire 15.0 m long has a diameter of 0.321 mm. When 1.50 Vis applied across the ends of the wire, the current is 0.0833 A. What is the resistivity of the material? A. 3.89 x 1070 m B. None of these answers Ос. 6.74 x 10 -10 O-m D. 9.71 x 10-80-m E 1.24 x 10-70m

  • A 5.0 V potential difference is applied between the ends of a 0.80-mm-diameter, 85-cm-long nichrome wire....

    A 5.0 V potential difference is applied between the ends of a 0.80-mm-diameter, 85-cm-long nichrome wire. What is the current in the wire? resistivity of nichrome is 1.5*10^-6 (I think, if im wrong use something else)
