The airspeed across the outside of an airplane window is 200 m/s . The cabin inside...
The airspeed across the outside of an airplane window is 200 m/s . The cabin inside is pressurezed to one atmosphere, and assume that the density of air is 1.29 kg/m3 on both sides of the window.
What is the pressure difference from inside to outside?
What is the force on the window if the window size is 28 cm by 44 cm ?
Homework Answers
Add Answer to:
The airspeed across the outside of an airplane window is 200 m/s
. The cabin inside...
consider an airplane window with the area of .31 m². If the pressure inside the airplane...
consider an airplane window with the area of .31 m². If the pressure inside the airplane is atmospheric pressure and the pressure inside is 23% of Patm what is the force of the window? Ignore the velocity of the airplane
Suppose a horizontal wind blows with a speed of 15.4 m/s outside a large pane...
Suppose a horizontal wind blows with a speed of 15.4 m/s outside a large pane of plate glass with dimensions 4.00x1.30m. Assume the density of the air to be 1.30 kg/m^3. The air inside the building is atmospheric pressure. I have already solved and verified the following but need help with (c): (a) What is the pressure difference on either side of the window pane? 154.15 Pa (b) What is the net force on the window pane? 801.6 N...
What is the net force on an airplane window of area 1000 cm2 if the pressure...
What is the net force on an airplane window of area 1000 cm2 if the pressure inside the cabin is 0.97 atm and the pressure outside is 0.85 atm? (Outward is defined as positive.)
An airplane is flying North with a airspeed of 200 m/s (i.e. the velocity relative to...
An airplane is flying North with a airspeed of 200 m/s (i.e. the velocity relative to the air). A strong wind is blowing East at 50 m/s. What is the airplane’s resultant velocity (magnitude and direction) relative to the ground?
Consider an airplane window (area 0.33 m2). If the pressure inside the plane is atmospheric pressure...
Consider an airplane window (area 0.33 m2). If the pressure inside the plane is atmospheric pressure and the pressure outside is 21% of Patm, what is the force on the window? Ignore the velocity of the airplane (i.e., ignore Bernoulli's effect). N
At high altitudes the air pressure can drop quite noticeably. What is the net force on...
At high altitudes the air pressure can drop quite noticeably. What is the net force on a 8.7x13 inch airplane window if at certain altitude the outside-cabin air pressure is Pout = 34 kPa and the inside-cabin pressure is supported at a level of Pin - 76.5 kPa? The net force on the window, Fnet - Units Select an answer If the same airplane window can withstand a twice as strong force as determined above, to what maximum value the...
An airplane wing was designed so that the speed of the air across the wing is...
An airplane wing was designed so that the speed of the air across the wing is 248 m/s when the speed of the air below the wing is 194 m/s. The density of the air is 1.29 kg/m^3. What is the lifting force on a wing of area 23.0 m^2?
An airplane wing is designed so that the speed of the air across the top of...
An airplane wing is designed so that the speed of the air across the top of the wing is 283 m/s when the speed of the air below the wing is 223 m/s. The density of the air is 1.29 kg/m3. What is the lifting force on a wing of area 22.0 m2?
An airplane wing generates lift due to a difference in air speed above and below the...
An airplane wing generates lift due to a difference in air speed above and below the wing. If the wings are both at the same height, what term is the same on both sides of the Bernoulli equation? Calculate the change in pressure (P-bottom - P_top) a wing experiences if the air moves at 245 m/s above the wing and 222m/s below the wing. The density of air is 1.29kg/m^3. Calculate the lift force the plane experiences if it has...
You are on the 48th floor of the Windom Hotel. The day is stormy, and you...
You are on the 48th floor of the Windom Hotel. The day is stormy, and you wonder whether the hotel is a safe place. The size of your room window is 0.80 m × 2.4 m . According to the weather report, gusts of up to 25 m/s are expected. Assume that such a gust suddenly blows by your window (parallel to the window), and that the pressure on both sides of the window is 1 atm before the gust....
At high altitudes the air pressure can drop quite noticeably. What is the net force on a 8.7x13 inch airplane window if at certain altitude the outside-cabin air pressure is Pout = 34 kPa and the inside-cabin pressure is supported at a level of Pin - 76.5 kPa? The net force on the window, Fnet - Units Select an answer If the same airplane window can withstand a twice as strong force as determined above, to what maximum value the...
An airplane wing generates lift due to a difference in air speed above and below the wing. If the wings are both at the same height, what term is the same on both sides of the Bernoulli equation? Calculate the change in pressure (P-bottom - P_top) a wing experiences if the air moves at 245 m/s above the wing and 222m/s below the wing. The density of air is 1.29kg/m^3. Calculate the lift force the plane experiences if it has...
