A solid disk with a c value of 1/2, mass of 3 kg, and radius of...
A solid disk with a c value of 1/2, mass of 3 kg, and radius of 1.5 meters lies on a horizontally (so the normal force and weight can be ignored). A force of 9 Newtons is applied 0.22 meters directly to the right of the center in the +x direction, a force of 24 Newtons is applied at 0.81 meters directly below of the center in the +x direction and a force of 8 Newtons is applied at the edge of the disk directly above the center in the +x direction. Again, ignoring the weight and normal force, what is the angular velocity of the disk after these forces are applied for 3 sec, in rad/s? If clockwise, include a negative sign.
Homework Answers
A solid disk with a c of 1/2, mass of 3 kg, and radius of 1.5...
A solid disk with a c of 1/2, mass of 3 kg, and radius of 1.5 meters lies on a horizontally (so the normal force and weight can be ignored). A force of 7 Newtons is applied 0.34 meters directly to the right of center in the +x direction, a force of 23 Newtons is applied 0.77 meters directly below of center in the +x direction, and a force of 7 Newtons is applied at the edge of the disk...
A 10 kg disk with a hole in its center has a c value about its...
A 10 kg disk with a hole in its center has a c value about its center of 0.56 has an outer radius of 3.6 meters. A force of 5 Newtons is applied in the -x direction at the edge of the disk directly to the right of its center. Another force of 28 Newtons is applied directly above the center in the -x direction halfway between the center and edge of the disk. Lastly, a force of 15 Newtons...
A 6 kg disk with a hole in its center has a c value about its...
A 6 kg disk with a hole in its center has a c value about its
center of 0.57 has an outer radius of 3.5 meters. A force of 9
Newtons is applied in the -x direction at the edge of the disk
directly to the right of its center. Another force of 34 Newtons is
applied directly above the center in the -x direction halfway
between the center and edge of the disk. Lastly, a force of 15
Newtons...
A 8 kg disk with a radius of 1 meters has several forces applied to it...
A 8 kg disk with a radius of 1 meters has several forces applied
to it as shown in the sketch. F1 is 41 N and is applied at the edge
of the disk, F2 is 7 N is applied at 1/4 the radius from the center
of the disk, F3 is 5 N is applied at 3/4 the radius from the
center, F4is 29 N is applied at the edge of the disk, and, lastly,
F5 is 16 N...
A disk with radius 0.6 meters and mass 31 kg is spinning about its own center with an angular velocity of 88ed A solid sphere (/ mR2) with a radius of 0.18 meters which is spinning with an angula...
A disk with radius 0.6 meters and mass 31 kg is spinning about its own center with an angular velocity of 88ed A solid sphere (/ mR2) with a radius of 0.18 meters which is spinning with an angular velocity of -18 ed (the negative sign indicates the opposite 6. rad sec direction), is gently lowered onto the disk a sticks to the disk. The two rotate together (about their mutual center of mass) at an angular velocity of 33...
A uniform disk with mass m = 8.55 kg and radius R = 1.35 m lies...
A uniform disk with mass m = 8.55 kg and radius R = 1.35 m lies in the xy plane and centered at the origin. Three forces act on the disk in the +y-direction (see figure below): (1) a force F1 = 335 N at the edge of the disk on the +x-axis, (2) a force F2 = 335 N at the edge of the disk on the ?y-axis, and (3) a force F3 = 335 N at the edge...
A uniform disk with mass m = 9.07 kg and radius R = 1.36 m lies...
A uniform disk with mass m = 9.07 kg and radius R = 1.36 m lies in the x-y plane and centered at the origin. Three forces act in the +y-direction on the disk: 1) a force 313 N at the edge of the disk on the +x-axis, 2) a force 313 N at the edge of the disk on the –y-axis, and 3) a force 313 N acts at the edge of the disk at an angle θ =...
1) A solid sphere with a radius of 1.3 meters and mass of 3.4 kg is...
1) A solid sphere with a radius of 1.3 meters and mass of 3.4 kg is pressed into a step with a height of 0.8 meters, by a force which is applied horizontally 0.5 meters above the center of the sphere (see sketch). When this force is applied, the sphere just starts to live off the ground and pivot around the corner of the step. How much is this force in Newtons?
A uniform disk with mass m = 9.31 kg and radius R = 1.43 m lies...
A uniform disk with mass m = 9.31 kg and radius R = 1.43 m lies in the x-y plane and centered at the origin. Three forces act in the +y-direction on the disk: 1) a force 349 N at the edge of the disk on the +x-axis, 2) a force 349 N at the edge of the disk on the –y-axis, and 3) a force 349 N acts at the edge of the disk at an angle θ =...
A uniform disk with mass m = 9.04 kg and radius R = 1.35 m lies...
A uniform disk with mass m = 9.04 kg and radius R = 1.35 m lies in the x-y plane and centered at the origin. Three forces act in the +y-direction on the disk: 1) a force 309 N at the edge of the disk on the +x-axis, 2) a force 309 N at the edge of the disk on the –y-axis, and 3) a force 309 N acts at the edge of the disk at an angle θ =...
A 6 kg disk with a hole in its center has a c value about its
center of 0.57 has an outer radius of 3.5 meters. A force of 9
Newtons is applied in the -x direction at the edge of the disk
directly to the right of its center. Another force of 34 Newtons is
applied directly above the center in the -x direction halfway
between the center and edge of the disk. Lastly, a force of 15
Newtons...
A 8 kg disk with a radius of 1 meters has several forces applied
to it as shown in the sketch. F1 is 41 N and is applied at the edge
of the disk, F2 is 7 N is applied at 1/4 the radius from the center
of the disk, F3 is 5 N is applied at 3/4 the radius from the
center, F4is 29 N is applied at the edge of the disk, and, lastly,
F5 is 16 N...
A disk with radius 0.6 meters and mass 31 kg is spinning about its own center with an angular velocity of 88ed A solid sphere (/ mR2) with a radius of 0.18 meters which is spinning with an angular velocity of -18 ed (the negative sign indicates the opposite 6. rad sec direction), is gently lowered onto the disk a sticks to the disk. The two rotate together (about their mutual center of mass) at an angular velocity of 33...
