Calculate the propelling force of a jet engine if its takes in air at a rate...

Question

Question

Calculate the propelling force of a jet engine if its takes in air at a rate of 100 kg/s and exhausts it at a speed of 500 m/s.

science physics

Answer 1

Answer #1

Answer 2

Similar Homework Help Questions

Air flows into the jet engine shown in Figure 3.2 at a rate of 130 kg/s...

Air flows into the jet engine shown in Figure 3.2 at a rate of 130 kg/s and a speed of 254 m/s. Upon landing, the engine exhaust exits through the reverse thrust mechanism with a speed of in the direction indicated. Determine the reverse thrust applied by the engine to the airplane. Assume the inlet and exit pressures are atmospheric and that the mass flowrate of fuel is negligible compared to the air flowrate through the engine. (8 marks) V3...
The thrust produced by a single jet engine creates a force of F = 84000 N....

The thrust produced by a single jet engine creates a force of F = 84000 N. It takes the jet (with a mass of m = 5200 kg) a distance of d = 0.78 km to take off. What is the take-off speed of the jet vt in m/s? How far in meters would you need to depress a giant spring k = 100,000 N/m in order to launch the jet at the same speed without help from the engine?
The thrust produced by a single jet engine creates a force of F = 84000 N....

The thrust produced by a single jet engine creates a force of F = 84000 N. It takes the jet (with a mass of m = 5200 kg) a distance of d = 0.78 km to take off. What is the take-off speed of the jet vt in m/s? How far in meters would you need to depress a giant spring k = 100,000 N/m in order to launch the jet at the same speed without help from the engine?

Air enters a nozzle in a jet engine at a pressure of 500 kPa, temperature of...

Air enters a nozzle in a jet engine at a pressure of 500 kPa, temperature of 650K, and velocity of 75 m/s. The air exits the nozzle at a pressure of 100 kPa, and the isentropic nozzle efficiency is 82%. a). Determine the velocity of the air at the nozzle exit. b). Determine the rate of entropy generation in the nozzle per kg of air flowing in kW/kgK
Calculate the force exerted on a rocket when the propelling gases are being expelled at a...

Calculate the force exerted on a rocket when the propelling gases are being expelled at a rate of 1400 kg/s with a speed of 4.0 times 10^4 m/s.
A jet aircraft with a mass of 4,675 kg has an engine that exerts a force...

A jet aircraft with a mass of 4,675 kg has an engine that exerts a force (thrust) equal to 59,500 N. (a) What is the jet's acceleration when it takes off? (Give the magnitude.) m/s2 (b)What is the jet's speed after it accelerates for 9 s? (Assume it starts from rest.) m/s (c) How far does the jet travel during the 9 s? m

The diffuser in a jet engine is designed to decrease the kinetic energy of the air entering the j...

The diffuser in a jet engine is designed to decrease the kinetic energy of the air entering the jet engine compressor without any work or heat interactions. Following information is recorded; Entering diffuser Velocity = 500 ms Pressure 100 kPa Temperature 20°0 The exit of a diffuser Velocity- 329.55 m/s Pressure 200 kPa Temperature- 90°0 The molecular mass of air = 28.96 kg/kmol Note for air, Cp/R-A+BT+CT2+DT2 ET3 with T in Kelvin Name Air B*103 0.575 D*10-5 0.016 C*106 E*109...
Problem 2: Calculate the thrust force generated by the jet fighter engine if the inlet air...

Problem 2: Calculate the thrust force generated by the jet fighter engine if the inlet air absolute velocity directed horizontally is Vin 300 ft/s and the exhaust gas absolute velocity directed upward by an angle 0 8° is Vout 1500 ft/s. The density of the air at the inlet is given by pair 0.00294 slugs/ft and the exhaust gas density is Pas 0.000845 slugs/ft. The jet fighter is moving at velocity Vev 250 f/s and engine cross sectional area at...
A 10,000 kg jet plane must reach a speed of 60 m / s for takeoff....

A 10,000 kg jet plane must reach a speed of 60 m / s for takeoff. If the jet engine increases its thrust at a rate of 20,000 N / s. Determine the time it takes for the aircraft to reach takeoff speed. Neglect air resistance and other forces.

Please provide step by step solution and i will give you a positive rating. Many thanks Air enters an airplane jet engine at a speed of 971 km/hr. The frontal intake area of the jet engine is 0.80 m2...

Please provide step by step solution and i will give you a positive rating. Many thanks Air enters an airplane jet engine at a speed of 971 km/hr. The frontal intake area of the jet engine is 0.80 m2 and the entering air density is 0.736 kg/m3 . The jet engine exhaust gases move away from the engine with a speed of 2021,km/hr. The engine exhaust area is 0.558 m2 , and the exhaust gas density is 0.515 kg/m3 ....
