There is a book attached to a rope, which is in turn connected to the end...
There is a book attached to a rope, which is in turn connected to the end of a spring, as show in Figure 2. The total length of the rope and unstretched spring is 60.0 cm. The rope cannot be stretched. The height of the shelf from the floor is 1.00 m. If k = 1000.0 N/m and the mass of the book is 2.0 kg, will the book hit the ground if it is slowly nudged off of the shelf? If not, find its minimum height above the floor.
Homework Answers
