An electronic system that is treated as particle in 3-D box with dimensions of 2Å x...

An electronic system that is treated as particle in 3-D box with dimensions of 2Å x 2Å x 4Å. Calculate the wavelength corresponding to the lowest energy transition if the system has 22 electrons. Calculate the wavelength corresponding to the lowest energy transition if the system has 22 electrons.

science   chemistry
0 0
Add a comment Improve this question Transcribed image text
Next > < Previous
Sort answers by oldest

Homework Answers

Answer #1

0 0
Add a comment
Know the answer?
Add Answer to:
An electronic system that is treated as particle in 3-D box with dimensions of 2Å x...
Your Answer:

Post as a guest

Your Name:

What's your source?

Earn Coins

Coins can be redeemed for fabulous gifts.

Log In

Sign Up

Not the answer you're looking for? Ask your own homework help question. Our experts will answer your question WITHIN MINUTES for Free.
Similar Homework Help Questions

  • Q 1: For particle in a box problem, answer the following questions, a) Why n=0 is...

    Q 1: For particle in a box problem, answer the following questions, a) Why n=0 is not an allowed quantum number? b) En = 0 is not allowed for particle in a box, why? c) Ground state wavefunction is orthogonal to the first excited state wavefunction, what does it mean? Q 2: An electronic system that is treated as particle in 3-D box with dimensions of 3Å x 3Å x 4Å. Calculate the wavelength corresponding to the lowest energy transition...

  • 1. Use the model of the particle in the ring (rotation in two dimensions) of quantum...

    1. Use the model of the particle in the ring (rotation in two dimensions) of quantum mechanics to describe the movement of electrons in the conjugate system of the benzene molecule. Presume that the circumference of the ring is equal to 8.40A. a. ((3 pts) Make a diagram of the energy levels of the electrons Pi in the benzene molecule, clearly identifying the HOMO and the LUMO. b. (3 pts) Calculate the energy of the HOMO and LUMO C. (3...

  • The following information pertains to a particle in a 2-D box. Both dimensions of the box...

    The following information pertains to a particle in a 2-D box. Both dimensions of the box are equal (Lx=Ly=L) Normalized Eigen functions: 1.  Ψ(x,y)= 2/L sin (nπx/L)sin( kπy/L) 2. H= h2/2m( d2/dx2+ d2/dy2)+ V (x,y) Boundary Conditions: V( x,y > 0; x,y < L) =0 V(x,y > L; x,y < 0 ) = Infinity a. Draw the 2-D potential energy surface ("box") that confines the particle. b. Use equations 2 and 3 to produce the general solution ( a formula in...

  • . The π-electrons of naphthalene(C10H8) can be considered to be confined to a rectangular box of dimension 4 A by 7 A (particle-in-a-box) 1) set up and solve the Schrodinger equation to find the energ...

    . The π-electrons of naphthalene(C10H8) can be considered to be confined to a rectangular box of dimension 4 A by 7 A (particle-in-a-box) 1) set up and solve the Schrodinger equation to find the energy levels. 2) Add the electrons to the energy-level diagram 3) which levels correspond to HOMO and LUMO? at what wavelength will the lowest energy transition occur?

  • 2. (a) When a particle of mass 1.0 x 10-26 g in a one-dimensional box goes...

    2. (a) When a particle of mass 1.0 x 10-26 g in a one-dimensional box goes from the n=3 level to n=1 level, it emits a radiation with frequency 5.0 x 1014 Hz. Calculate the length of the box. (b) Suppose that an electron freely moves around inside of a three-dimensional rectangular box with dimensions of 0.4 nm (width), 0.4 nm (length), and 0.5 nm (height). Calculate the frequency of the radiation that the electron would absorb during its transition...

  • CHEM20020 Structure and Properties Question 8. [time = 10 minutes) Benzene (C6H) has a cyclic structure...

    CHEM20020 Structure and Properties Question 8. [time = 10 minutes) Benzene (C6H) has a cyclic structure with Dh symmetry. Using a particle-on-a-ring model calculate the energy and wavelength for the lowest electronic trans elength for the lowest electronic transition of the benzene molecule. Clearly explain (using a diagram) which energy levers are sing a diagram) which energy levels are involved in the transition. Make the following assumptions: 1. The r electrons can be approximated as moving on a 2-D ring....

  • The π-electrons of naphthalene(C10H8) can be considered to be confined to a rectangular box of dimension...

    The π-electrons of naphthalene(C10H8) can be considered to be confined to a rectangular box of dimension 4 A by 7 A (particle-in-a-box) 1) set up and solve the Schrodinger equation to find the energy levels. 2) Add the electrons to the energy-level diagram 3) which levels correspond to HOMO and LUMO? at what wavelength will the lowest energy transition occur?

  • D U LULUI LUULISILY 3. A 100 N rectangular box has dimensions 50 cm x 20...

    D U LULUI LUULISILY 3. A 100 N rectangular box has dimensions 50 cm x 20 cm x 20 cm. If the box is placed on a horizontal table, calculate the (a) lowest pressure and (b) highest pressure that the box can exert on the table. Attach File

  • A free-electron model for a benzene molecule can be approximated via a particle rotating in a...

    A free-electron model for a benzene molecule can be approximated via a particle rotating in a ring (2-D rigid rotor problem). Use this model assuming the radius of benzene of 1.39 ˚A to answer the following questions: a) Find the energies of the occupied electronic levels; plot a schematic diagram of the electronic levels. b) Calculate the wavelength (in nm) of the lowest-energy electronic transition in benzene. c) In what region of the electromagnetic spectrum is this transition? How does...

  • Consider a particle in a 3D box in which the longest wavelength transition for this system...

    Consider a particle in a 3D box in which the longest wavelength transition for this system occurs at 200 nm. What is the wavelength of the transition if (a) the particle’s mass is doubled? (b) the particle’s charge is doubled? (c) the size of the box is halved?
