If the Closed-Lopp Transfer Function of the system is G(s) = (KR/2L)/Ts^2+s+KR/2L, and T=0.1, R/2L =...
If the Closed-Lopp Transfer Function of the system is G(s) = (KR/2L)/Ts^2+s+KR/2L, and T=0.1, R/2L = 0.5, K= 1.8, what is the response of the system to step input?
Is there something I am missing?
Homework Answers
Add Answer to:
If the Closed-Lopp Transfer Function of the system is G(s) =
(KR/2L)/Ts^2+s+KR/2L, and T=0.1, R/2L =...
