Just prior to impact with a golf ball (0.044 kg), a clubhead (0.206 kg) is travelling...
Just prior to impact with a golf ball (0.044 kg), a clubhead (0.206 kg) is travelling with a velocity of 43.6 m/s horizontally towards the target and a vertical velocity of 0 m/s. The coefficient of restitution between the ball and club is 0.79. Impact lasts for 0.00045 s. The launch angle of the ball after impact is 9.1°. During impact the ball behaves as a linear spring with a stiffness of, K= 1114411, and is maximally compressed from its resting state by Δx = 0.01 m.
What was the average force, exerted in the target (x, horizontal) direction, on the ball by the clubhead during the time of impact?
