A bob of mass 0.320 kg is attached to one end of a light inextensible string...
A bob of mass 0.320 kg is attached to one end of a light inextensible string of length 0.600 m, whose other end is attached to a fixed pivot. The bob performs uniform circular motion in a horizontal plane, with the string making an angle of 30.0° with the vertical. What is the angular speed of this circular motion? Give your answer in raduans.
(Hint: you can begin by using Newton's second law in the vertical direction to find the tension in the string.)
(Hint: you can begin by using Newton's second law in the vertical direction to find the tension in the string.)
Homework Answers
Add Answer to:
A bob of mass 0.320 kg is attached to one end of a light
inextensible string...
just question 3a 3b Simple harmonic motion: pendulums Equipment Pendulum bobs String and support Meter stick...
just question 3a 3b
Simple harmonic motion: pendulums Equipment Pendulum bobs String and support Meter stick & mass balance Photogate & Smart Timer Preliminary question 1. Describe simple harmonic motion in your own words. 2. Describe how mechanical energy is conserved during a pendulum's swing. 3. You have a 30.0 g pendulum bob attached to a string that is 50.0 cm long. You raise the bob so that the string makes a 20.0° angle with the vertical (as shown) and...
A pendulum is 0.864 m long and the bob has a mass of 1.04 kg. When...
A pendulum is 0.864 m long and the bob has a mass of 1.04 kg. When the string makes an angle of θ= 14.8 degrees with the vertical, the bob is moving at 1.44 m/s. Find the tangential and radial acceleration components and the tension in the string. (Hint: Draw an FBD for the bob. Choose the x-axis to be tangential to the motion of the bob and the y-axis to be radial. Apply Newton's second law.) at = ______...
Exercise 4: A small ball of mass m, is attached to the end of string of...
Exercise 4: A small ball of mass m, is attached to the end of string of length L and negligible mass. The other end of string is attached to a pivot located on a ceiling. The system forms a simple pendulum. Analyze the torques on the ball about the pivot on the ceiling when the ball makes an angle with respect to the vertical. Sketch Coordinate system e-FBD of m Newton's and law analysis
One end of a cord is fixed and a 0.5 kg object is attached to the...
One end of a cord is fixed and a 0.5 kg object is attached to the other end, where it swings in a vertical circular motion of radius 2 m. When the angle is 20 degree, the speed of the object is 8 m/s. At this instant find the tension in the string, and the radial acceleration.
A pendulum consists of a 2.5-kg bob attached to a light 1.2 m-long string. While hanging...
A pendulum consists of a 2.5-kg bob attached to a light 1.2 m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 3m/s. At the instant the string makes an angle of 38 degree with the vertical, what is The speed, The tension in the string? What is the angle of the string with the vertical when the bob reaches its greatest
A pendulum consists of a 1.9-kg bob attached to a light 2.3-m-long string. While hanging at...
A pendulum consists of a 1.9-kg bob attached to a light 2.3-m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 4.1 m/s. At the instant the string makes an angle of 30° with the vertical, calculate the following: speed= 3.28 m/s gravitational potential energy is 5.739 J what is the tension in the string in Newtons? what is the angle of the string with the...
A pendulum consists of a 1.7-kg bob attached to a light 2.6-m-long string. While hanging at...
A pendulum consists of a 1.7-kg bob attached to a light 2.6-m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 5.0 m/s. At the instant the string makes an angle of 28° with the vertical, calculate the following (a) the speed m/s (b) the gravitational potential energy (relative to its value is at the lowest point) (c) the tension in the string? (d) What is...
A pendulum consists of a 2.2-kg bob attached to a light 2.0-m-long string. While hanging at...
A pendulum consists of a 2.2-kg bob attached to a light 2.0-m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 4.5 m/s. At the instant the string makes an angle of 27 degree with the vertical, calculate the following: (a) the speed m/s (b) the gravitational potential energy (relative to its value is at the lowest point) J (c) the tension in the string? N...
A stone with a mass of 0.700 kg is attached to one end of a string...
A stone with a mass of 0.700 kg is attached to one end of a string 0.800 m long. The string will break if its tension exceeds 50.0 N. The stone is whirled in a horizontal circle on a frictionless tabletop; the other end of the string remains fixed. A. Find the maximum speed the stone can attain without breaking the string.
An inextensible massless string of length 2l has mass mand m3 attached to the two ends...
An inextensible massless string of length 2l has mass mand m3 attached to the two ends A and B respectively. A particle of mass m2 is attached to the midpoint of the string at point C. Initially, the three particles are at the vertices of an equilateral triangle as shown in the figure below and the string is taut. Particle 2 is given an impulse J along the bisector of the angle ACB. It is known that the whole set...
just question 3a 3b
Simple harmonic motion: pendulums Equipment Pendulum bobs String and support Meter stick & mass balance Photogate & Smart Timer Preliminary question 1. Describe simple harmonic motion in your own words. 2. Describe how mechanical energy is conserved during a pendulum's swing. 3. You have a 30.0 g pendulum bob attached to a string that is 50.0 cm long. You raise the bob so that the string makes a 20.0° angle with the vertical (as shown) and...
Exercise 4: A small ball of mass m, is attached to the end of string of length L and negligible mass. The other end of string is attached to a pivot located on a ceiling. The system forms a simple pendulum. Analyze the torques on the ball about the pivot on the ceiling when the ball makes an angle with respect to the vertical. Sketch Coordinate system e-FBD of m Newton's and law analysis
One end of a cord is fixed and a 0.5 kg object is attached to the other end, where it swings in a vertical circular motion of radius 2 m. When the angle is 20 degree, the speed of the object is 8 m/s. At this instant find the tension in the string, and the radial acceleration.
A pendulum consists of a 2.5-kg bob attached to a light 1.2 m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 3m/s. At the instant the string makes an angle of 38 degree with the vertical, what is The speed, The tension in the string? What is the angle of the string with the vertical when the bob reaches its greatest
A pendulum consists of a 1.7-kg bob attached to a light 2.6-m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 5.0 m/s. At the instant the string makes an angle of 28° with the vertical, calculate the following (a) the speed m/s (b) the gravitational potential energy (relative to its value is at the lowest point) (c) the tension in the string? (d) What is...
A pendulum consists of a 2.2-kg bob attached to a light 2.0-m-long string. While hanging at rest with the string vertical, the bob is struck a sharp horizontal blow, giving it a horizontal velocity of 4.5 m/s. At the instant the string makes an angle of 27 degree with the vertical, calculate the following: (a) the speed m/s (b) the gravitational potential energy (relative to its value is at the lowest point) J (c) the tension in the string? N...
An inextensible massless string of length 2l has mass mand m3 attached to the two ends A and B respectively. A particle of mass m2 is attached to the midpoint of the string at point C. Initially, the three particles are at the vertices of an equilateral triangle as shown in the figure below and the string is taut. Particle 2 is given an impulse J along the bisector of the angle ACB. It is known that the whole set...
