A glider with mass m = 0.200 kg sits on a frictionless horizontal air track, connected...
A glider with mass m = 0.200 kg sits on a frictionless horizontal air track, connected to a spring with force constant k = 5.20 N/m . You pull on the glider, stretching the spring 0.130 m , and then release it with no initial velocity. The glider begins to move back toward its equilibrium position ( x=0 ).
Part A
What is the speed of the glider when it returns to x=0 ?
Part B
What must the initial displacement of the glider be if its maximum speed in the subsequent motion is to be 2.40 m/s ?
Homework Answers
Add Answer to:
A glider with mass m = 0.200 kg sits on a frictionless
horizontal air track, connected...
A glider with mass m = 0.5 kg sits on a frictionless air track. It is...
A glider with mass m = 0.5 kg sits on a frictionless air track. It is connected to a massless spring with force constant k = 40 N/m. The glider is initially at x=0, and the spring is relaxed. You then hit the glider with a hammer, which gives it an initial velocity of υ0 = 5 m/s in the positive x direction. At what x positions will the speed of the glider be zero?
A glider with mass m=0.200kg sits on a frictionless horizontal air track, connected to a spring...
A glider with mass m=0.200kg sits on a frictionless horizontal air track, connected to a spring of negligible mass with force constant k=5.00N/m. Suppose the glider is initially at rest at x=0, with the spring unstretched. Then you apply a constant force F⃗ with magnitude 0.583 N to the glider. What is the glider’s speed when it has moved to x=0.100m? If the 0.583 N force is removed when the glider reaches the 0.100 m point, at what distance from...
A glider with mass m=0.200kg sits on a frictionless horizontal air track, connected to a spring...
A glider with mass m=0.200kg sits on a frictionless horizontal air track, connected to a spring of negligible mass with force constant k=5.00N/m. Suppose the glider is initially at rest at x=0, with the spring unstretched. Then you apply a constant force F⃗ with magnitude 0.650 N to the glider. What is the glider’s speed when it has moved to x=0.100m? If the 0.650 N force is removed when the glider reaches the 0.100 m point, at what distance from the...
Now let’s use the concept of elastic potential energy to solve a problem involving a spring....
Now let’s use the concept of elastic potential energy to solve a problem involving a spring. A glider with mass m=0.200kg sits on a frictionless horizontal air track, connected to a spring of negligible mass with force constant k=5.00N/m. You pull on the glider, stretching the spring 0.100 m, and then release it with no initial velocity. The glider begins to move back toward its equilibrium position (x=0). What is its speed when x=0.0800m? Part a: What is the value...
Problem 2 A 0.175-kg glider on a horizontal, frictionless air track is attached to a fixed...
Problem 2 A 0.175-kg glider on a horizontal, frictionless air track is attached to a fixed ideal spring with spring constant 155 N/m. When the glider is 3.00 cm from its equilibrium point, it is moving at 0.815 m/s. (a) Find the frequency of the oscillations. (b) Find the amplitude of the motion. (c) Find the maximum speed of the glider. Hint: For (b) and (c), use the energy conservation.
6. An air-track glider is connected to an ideal spring and can oscillate back and forth on the fr...
6. An air-track glider is connected to an ideal spring and can oscillate back and forth on the frictionless surface of the track. The potential energy function of the spring/glider system is U(x) 2.024.0 1.0 in Joules. Here represents the position of the center of the glider in meters. The graph of this function is provided. The y-axis is in Joules and the x- axis is in meters. a. What is the a-coordinate of the center of the glider when...
A 330 g air-track glider attached to a spring with spring constant 11 N/m is sitting...
A 330 g air-track glider attached to a spring with spring constant 11 N/m is sitting at rest on a frictionless air track. A 330 g glider is pushed toward it from the far end of the track at a speed of 120 cm/s . It collides with and sticks to the 330g glider. What is the amplitude of the subsequent oscillations? What is their period?
A 750 g air-track glider attached to a spring with spring constant 8.00 N/m is sitting...
A 750 g air-track glider attached to a spring with spring constant 8.00 N/m is sitting at rest on a frictionless air track. A 225 g glider is pushed toward it from the far end of the track at a speed of 154 cm/s . It collides with and sticks to the 750 g glider. What is the amplitude of the subsequent oscillations? What is their period?
An air-track glider of mass 0.100 kg is attached to the end of a horizontal air...
An air-track glider of mass 0.100 kg is attached to the end of a horizontal air track by a spring with force constant 20.0 N/m. Initially the spring is unstreched and the glider is moving at 1.50 m/s to the right. With the air track turned off, the coefficient of kinetic friction is μk=0.47. It can be shown that with the air track turned off, the glider travels 8.6 cm before it stops instantaneously. If the coefficient of static friction...
In the physic lab, an air-track glider of mass m is on a frictionless air track...
In the physic lab, an air-track glider of mass m is on a
frictionless air track inclined at an angle θ as is shown in the
adjacent figure.
a)- Find the acceleration of the air-track glider.
b)- supposed the air-track glider is released from rest at the
top of the incline and the distance from the glider's front bumper
to the bottom of the incline is D (or what is the same, the
distance from the top of the incline...
Problem 2 A 0.175-kg glider on a horizontal, frictionless air track is attached to a fixed ideal spring with spring constant 155 N/m. When the glider is 3.00 cm from its equilibrium point, it is moving at 0.815 m/s. (a) Find the frequency of the oscillations. (b) Find the amplitude of the motion. (c) Find the maximum speed of the glider. Hint: For (b) and (c), use the energy conservation.
6. An air-track glider is connected to an ideal spring and can oscillate back and forth on the frictionless surface of the track. The potential energy function of the spring/glider system is U(x) 2.024.0 1.0 in Joules. Here represents the position of the center of the glider in meters. The graph of this function is provided. The y-axis is in Joules and the x- axis is in meters. a. What is the a-coordinate of the center of the glider when...
In the physic lab, an air-track glider of mass m is on a
frictionless air track inclined at an angle θ as is shown in the
adjacent figure.
a)- Find the acceleration of the air-track glider.
b)- supposed the air-track glider is released from rest at the
top of the incline and the distance from the glider's front bumper
to the bottom of the incline is D (or what is the same, the
distance from the top of the incline...
